Features:
-
Side blade guides eccentric shaft, ball bearing
-
Rear blade guides ball bearings
-
Blade drive is steel, heat treated worm, driving a
bronze worm gear in oil bath
-
Heavy-duty cast iron saw head and table
-
Oil bath hardened and ground worm gear
-
Adjustable ball bearing blade guides
-
Blade wheels are made of flanged cast iron
-
Adjustable hydraulic feed system
-
Automatic shut-off at end of cut
-
Rapid acting vise
-
Coolant pump 1 gallon, 1Ph motor, complete with hose,
flexible nozzle, shut-off valve, tank and baffle
-
Wheel kit for convenient moving to various work stations
-
3/4" bi-metal blade
-
Adjustable material stop
|
 |
|
Specifications |
| Part Number |
414454 |
|
Model Number |
J-3410 |
| Motor |
3/4HP, 115V, 1Ph,
1725RPM |
|
Round at 90 Degrees (in.) |
7 |
| Round at 45 Degrees
(in.) |
6 |
|
Rectangle at 90 Degrees (in.) |
7 x
10 |
| Square at 90 Degrees
(in.) |
7 |
|
Blade Size (in.) |
3/4
x .035 x 93 |
| Blade Speeds (SFPM) |
86-132-178-260 |
| Bed
Height (in.) |
23-1/2 |
| Height |
41 inch |
|
Width |
18
inch |
| Length |
50 inch |
| Net
Weight |
360
pound |
|
|
WMH414454
