Compaction Output (yd3/h) at recommended soil layer
thicknesses. |
|
Model |
Rock Fill |
Gravel, Sand |
Mixed Soil |
Silt, Clay |
|
BPR25/40 |
- |
15-24 |
13-20 |
8-12 |
|
BPR25/40D |
- |
15-24 |
13-20 |
8-12 |
|
Note:
The reference
values in the above table are the result of compaction
trials and practical applications. Under normal
application conditions the required compaction values
will be reached after four to eight passes. |
|
|
Specifications |
|
Model |
BPR25/40 |
BPR25/40D |
|
Weights |
|
Basic weight - lbs (kg) |
238 (108) |
278 (126) |
|
Operating weight - lbs (kg) |
245 (111) |
284 (129) |
|
Driving
characteristics (depending on site conditions) |
|
Working speed max - ft/min (m/min) |
82 (25) |
82 (25) |
|
Max. gradeability - % |
30 |
30 |
|
Drive |
|
Engine manufacturer |
Honda |
Hatz |
|
Type |
GX 160 |
1B20 |
|
Cooling |
air |
air |
|
Number of cylinders |
1 |
1 |
|
Performance ISO 9249 - hp (kW) |
5.43 (4) |
4.21 (3.1) |
|
Speed |
3600 |
3000 |
|
Performance SAE - hp (kW) |
5.36 (4) |
4.15 (3.1) |
|
Speed - rpm |
3600 |
3000 |
|
Fuel |
gasoline |
diesel |
|
Exciter System |
|
Frequency - vpm (Hz) |
5100 (85) |
5100 (85) |
|
Centrifugal Force - lbs (kN) |
5625 (25) |
5625 (25) |
|
Capacities |
|
Fuel - gal (l) |
0.8 (3) |
0.8 (3) |
|
Technical modifications reserved. Machine
may be shown with options. |
|
