Specifications |
|
Model |
BPR35/60 |
|
Weights |
|
Basic weight - lbs (kg) |
728 (330) |
|
Operating weight (W) - lbs (kg) |
710 (322) |
|
Operating weight (W1) - lbs (kg) |
739 (335) |
|
Operating weight (W2) - lbs (kg) |
778 (353) |
|
Dimensions |
|
Standard working width (W1) - in (mm) |
21.7 (550) |
|
Working width w/o extensions bars (W) - in
(mm) |
17.7 (450) |
|
Lowest passing height - in (mm) |
29.5 (750) |
|
Driving
characteristics (depending on site conditions) |
|
Working speed max - ft/min (m/min) |
88.6 (27) |
|
Max. gradeability - % |
35 |
|
Drive |
|
Engine manufacturer |
Honda |
|
Type |
GX 270 |
|
Cooling |
air |
|
Number of cylinders |
1 |
|
Performance ISO 9249 - hp (kW) |
9.0 (6.6) |
|
Speed |
3600 |
|
Performance SAE - hp (kW) |
8.9 (6.6) |
|
Speed - rpm |
3600 |
|
Drive System |
mech |
|
Fuel |
gasoline |
|
Exciter System |
|
Frequency - vpm (Hz) |
4200 (70) |
|
Centrifugal Force - lbs (kN) |
10125 (45) |
|
Capacitie |
|
Fuel - gal (l) |
1.6 (6) |
|
Technical modifications reserved. Machine
may be shown with options. |
