Specifications |
|
Model |
BPR45/55D |
BPR55/65D |
|
Weights |
|
Basic Operating weight - lbs (kg) |
862 (391) |
994 (451) |
|
Operating weight (W1) - lbs (kg) |
840 (381) |
961 (436) |
|
Operating weight (W2) - lbs (kg) |
873 (396) |
1005 (456) |
| Operating
weight (W3) - lbs (kg) |
908 (412) |
1030 (467) |
|
Dimensions |
|
Standard working width (W1) - in (mm) |
21.7 (550) |
25.6 (650) |
|
Working width w/o extensions bars (W) - in
(mm) |
17.7 (450) |
17.7 (450) |
|
Lowest passing height - in (mm) |
31.1 (790) |
31.1 (790) |
|
Driving
characteristics (depending on site conditions) |
|
Working speed max - ft/min (m/min) |
92 (28) |
92 (28) |
|
Max. gradeability - % |
35 |
35 |
|
Drive |
|
Engine manufacturer |
Lombardini |
Lombardini |
|
Type |
15 LD 440 |
15 LD 440 |
|
Cooling |
air |
air |
|
Number of cylinders |
1 |
1 |
|
Performance ISO 9249 - hp (kW) |
9.0 (6.6) |
9.0 (6.6) |
|
Speed |
3000 |
3000 |
|
Performance SAE - hp (kW) |
8.9 (6.6) |
8.9 (6.6) |
|
Speed - rpm |
3000 |
3000 |
|
Drive system |
mechanical |
mechanical |
|
Fuel |
diesel |
diesel |
|
Vibratory System |
|
Frequency - bpm (Hz) |
4200 (70) |
3960 (66) |
|
Compaction depth max - in (cm) |
10125 (45) |
12375 (55) |
|
Capacities |
|
Fuel - gal (l) |
1.3 (5) |
1.3 (5) |
|
Technical modifications reserved. Machine
may be shown with options. |
