Compaction Output (cu. yd/h) at recommended soil layer/lift
thickness. * |
|
Model |
Gravel, Sand |
Mixed Soils |
Silt, Clay |
|
BP8/34 |
10.5 - 15.7 |
10.5 - 15.7 |
- |
|
Compaction Output (ton/h) at different asphalt layer/lift
thickness. * |
|
Model |
1in |
2in |
3in |
|
BP8/34 |
4.4 |
8.8 |
13.2 |
|
* Compaction output influenced by
soil/material type and moisture content. |
|
|
Specifications |
|
Model |
BP10/36-2 |
|
Weights |
|
Basic weight - lbs (kg) |
117 (53) |
|
Operating weight - lbs (kg) |
119 (54) |
|
Dimensions |
|
Ground contact area - in² (cm²) |
165 (1063) |
|
Basic working width - in (mm) |
13.4 (340) |
|
Driving
characteristics (depending on site conditions) |
|
Working speed max - ft/min (m/min) |
72.2 (22) |
|
Max. gradeability - % |
30 |
|
Drive |
|
Engine manufacturer |
Honda |
|
Type |
GX 120 |
|
Cooling |
air |
|
Number of cylinders |
1 |
|
Performance ISO 9249 - hp (kW) |
3.9 (2.9) |
|
Speed |
3000 |
|
Performance SAE - hp (kW) |
3.9 (2.9) |
|
Speed - rpm |
3000 |
|
Drive system |
mechanical |
|
Fuel |
gasoline |
|
Vibratory System |
|
Frequency - bpm (Hz) |
5400 (90) |
|
Compaction depth max - in (cm) |
2250 (10) |
|
Capacities |
|
Fuel - gal (l) |
0.7 (2.5) |
|
Water - gal (l) |
1.7 (6.5) |
|
Technical modifications reserved. Machine
may be shown with options. |
|
