Blade Capacity
|
12” OD (406mm); saw blades not included.
|
|
Arbor
|
1” (25mm) with 2-1/2” (64mm) saw collars;
3700 RPM of spindle.
|
|
Motors & Voltage
|
3 H.P. 3 Phase 230/460 Volt Totally Enclosed Fan Cooled Motor, 60 Hz,
3450 RPM optional starter available
for voltage protection.
|
|
Compound of Tilting Angle |
Saw head will compound angle
cut up to 45° in direction shown, with positive
pin stops at 90°, 22-1/2°, and 45°. Saw
will cut up to 10° on the other side of the
vertical plane. |
| Actuation |
Hand operated standard; optional power downfeeds of sawheads actuated by Two-Hand, Anti-Tie Down Maintained Contact Safety Control. |
| Cutting Capacity |
45° Mitre; 3-1/4” (82mm) High x
5”
(127mm) Wide 90° Straight Cut; 2-1/2” (63mm) High x
7”
(178mm) Wide 90° Front to Back/45° Compound;
1”
(25.4mm) High x 7” (178mm) Wide. |
| Optional Extras Include |
Power Downfeeds of Sawheads,
Clamps, Measuring Fences and Table Supports. |
