Blade Capacity
|
12" OD (305mm) standard.
|
| Spindle & Pivot |
have preloaded, sealed ball bearings; .001 alignment of spindle and pivot. |
|
Arbor
|
1" (25.4mm) OD with 2-1/2" (64mm) saw collars; 3700 RPM.
|
|
Motors & Starters
|
2 H.P. 1 or 3 Phase totally enclosed fan cooled with toggle switch; enclosed 2-belt drive.
|
| Iron Castings |
Base & disc are made from precision machined iron castings for lasting accuracy. Disc is set flush with table and graduated each degree. |
|
Blade Guard
|
Completely encloses blade in rest position. Lower rotating blade guard pivots up into main stationary blade guard as saw heads pivot down to cut.
|
|
Size & Weight
|
22”(56cm) wide x 27”(69cm) front to
back x 22-1/2”(57cm) high
150 lbs. (68kgs)
|
| Actuation |
.Manual hand operation; optional power feed of saw head. |
| Dust Outlet |
Two 2" dust outlet provided. 600 CFM required for each. |
| Table Base |
Made of iron castings, precision machined and ground with milled slots to guide fences. Sawhead is fixed at 90°. Fence Brackets are fit to milled keyways in base and are easily adjustable front to rear. |
