How It Works
The *Lectro-Truck* enables the user to gain a mechanical advantage over the load being moved. Climbing stairs, loading onto the back of a truck, or just even moving a heavy load around on a flat surface - all are made a lot easier by using the *Lectro-Truck*. Click here to see the Lectro-Truck in action (8.51MB File)
The Old Way The old way has four men hoisting a water heater up a flight of steps. They are lifting this water heater relying on the "1-2-3...grunt" technique. Furthermore, each man is responsible for 150+ pounds of lifting!! The old way leads to higher manpower costs, back injuries, product and property damage.	The Lectro-Truck Way The *Lectro-Truck* way has one man doing the same job as the four men in the previous picture. He is lifitng the water heater using the power and balance of the *Lectro-Truck* - and is responsible for lifting no weight!! The *Lectro-Truck* way leads to increased profits in less manpower, fewer injuries, and lower product and property damage
Stair Climbing Progression
Step #1: After you roll your *Lectro-Truck* to the base of the steps, power the "Wheels Up" button to approximately the height of the second step up	Step #2: Tip the *Lectro-Truck* back and set the wheels on the second step, leaving an empty step (the first). By raising the wheels, you have also raised the handles of the *Lectro-Truck* - giving the user better leverage
Step #3: With the wheels set in place on the second step, lean down and back on the top of the *Lectro-Truck. This will raise the load off the ground, and will also roll the wheels back to the rear of the step. Now power the "Load Up" button to make the Lectro-Truck* lift the load onto the first step	Step #4: When the load is set on the first step, lean the *Lectro-Truck* slightly forward and power the "Wheels Up" button so the wheels come up to the third step
Step #5: Now that your wheels are on the third step, counterbalance the load and power it up to the second step. Keep repeating this procudure until you have reached the top of the steps
Frequently Asked Questions
How long does the battery last? The best way to accurately measure the number of steps you can expect is to determine the weight of the item(s) you are going to move. The length and strength of the charge will be determined by this weight. On our larger units (all models except the LTA4512E), with a fully-charged battery, you can expect the following performance: 500 lbs. = 400 steps 1,000 lbs. = 200 steps 1,500 lbs. = 75 steps	*Can the Lectro-Truck* go off the back of a truck? Yes, the Lectro-Truck can be used as a powered lift gate. If your truck bed (or the floor of your trailer) is less than 41", certain Lectro-Truck** models will reach. We always suggest using the Hook Box accessory to properly secure your load in place. For your information, here are the lifting heights of all the machines we sell: LTA6512E* = 41" LTA5512E* = 41" LTA5012E = 33" LTA4512E = 33" 1268E* = 39" 1260E* = 39" *Equipped with a hook bar
*How much weight will the Lectro-Truck* lift? The Lectro-Truck is able to lift the full** weight that is listed as capacity. This is the same whether you are moving across flat surfaces, up or down steps, or onto and off of trucks and trailers. This is very simply because, we use stronger, more reliable components. As a reminder, here are the capacities again: LTA6512E = 1,500 lbs. LTA5512E = 1,200 lbs. LTA5012E = 1,200 lbs. LTA4512E = 600 lbs. 1268E = 1,500 lbs. 1260E = 1,500 lbs.	Why do my wheels keep rolling towards the front of the step? The wheels on the Lectro-Truck will roll forward for a few different reasons. One reason might be that the step is too deep. When you go to raise the load up to the next step if the wheels are too far back on the step the inner frame will ride on the edge of the step and pull the Lectro-Truck forward. To correct this problem we have wheel brakes that attach to the Lectro-Truck's wheels and prevent the wheels from rolling forward. A second reason why your Lectro-Truck might roll towards the front of the step is because the load you are moving is too short and heavy. The way to correct this problem is by using the Balance Box accessory - or some other means to raise the center of gravity. This will move the weight up on the Lectro-Truck to equally distribute the weight and allow the user to gain a mechanical advantage over the load being moved. A third reason your Lectro-Truck wheels will roll towards the front of the step is because the step might be pitched forward. To correct this problem we would suggest installing the wheel brakes.
*What if I need to rest in the middle of the flight of steps with a 1500 lb. load on my Lectro-Truck?* The *Lectro-Truck's* mast-type frame allows you to adjust the wheels up one or two steps - all while the load is resting safely on its own step. Once you have obtained a healthy balance on the steps, you can let go of the *Lectro-Truck's* handles and let the load rest in place. Other stair climbing hand trucks that do not have the mast-type frame do not allow the user to do this.	What happens if my battery goes dead during a move? If your battery should go dead in the middle of your move, balance the Lectro-Truck on the steps, and replace the battery or swap the detachable battery pack. (Extra battery packs can be purchased to eliminate this scenario.) *Where is the Lectro-Truck* made? The Lectro-Truck** is manufactured in Oostburg, WI.
