Birmingham Double Pinch Plate Rolls

Double Pinch Hydraulic Brake Rolls
RH-0606
RH-1006

Features

  • Hydraulic circuits, which is protected against overload, is fully

  • All three rolls driven independently and hydraulically

  • Hydraulic pinch adjustment for two lower rools

  • Each lower roll is equipped with an easy-reading LED indicator to show its reference position to the operator

  • Hydraulic pinch adjustment can be easily adjusted from the LED indicator reading

  • Portable controller around the machine for rolls forward/reverse/pinch adjustment conveniently

  • All rolls are made of top grade alloy steel hardened up to HRC55

  • Spherical roller bearings, which are very high quality made and sealed-in to keep out dirt and dust, are installed for all rools

Optional Accessories

  • Infinitely variable roll rotation speed

  • Cone bending attachment

CPTRH-0506
$31,625.00 $30,481.44
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 5'X1/4"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

rh-0606.jpg CPTRH-0606
$34,562.50 $33,312.72
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 6'X1/4"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0805
$39,375.00 $37,951.20
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 8'X6Ga DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-1004
$41,500.00 $39,999.36
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 10'X7Ga, DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0508
$34,375.00 $33,132.00
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 5'X5/16"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0608
$37,500.00 $36,144.00
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 6'X5/16"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0806
$42,625.00 $41,083.68
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 8'X1/4"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-1005
$49,375.00 $47,589.60
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 10'X6 Ga, DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0510
$41,437.50 $39,939.12
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 5'X3/8"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0610
$48,062.50 $46,324.56
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 6'X3/8"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0808
$54,250.00 $52,288.32
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 8'X5/16"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

rh-1006.jpg CPTRH-1006
$61,250.00 $59,035.20
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 10'X1/4"", Ga DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0613
$64,125.00 $61,806.24
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 6'X1/2"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0810
$69,625.00 $67,107.36
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 8'X3/8"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-1008
$78,212.50 $75,384.34
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 10'X5/16"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0616
$80,937.50 $78,010.80
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 6'X5/8"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-0813
$90,750.00 $87,468.48
"HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 8'X1/2"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-1010
$98,750.00 $95,179.20
"1HEAVY DUTY HYDRAULIC BENDING ROLLS, DOUBLE PINCH TYPE 0'X3/8"", DOUBLE PINCH ::::::: Call 1-800-458-3687 For Freight Rate on This Item!"

CPTRH-CBA
$2,125.00 $2,048.16
Cone bending attachment ::::::::FREE FREIGHT On This Order Only When Ordered With A Birmingham Machine or See UPS Chart at Check Out for Freight Rate!

CPTRH-0506-IVR
$4,000.00 $3,855.36
Infinity variable roll rotation speed for RH-0506 to 1006 ::::::::FREE FREIGHT On This Order Only When Ordered With A Birmingham Machine or See UPS Chart at Check Out for Freight Rate!

CPTRH-0613-IVR
$6,875.00 $6,626.40
Infinity variable roll rotation speed for RH-0613 to RH-1010 ::::::::FREE FREIGHT On This Order Only When Ordered With A Birmingham Machine or See UPS Chart at Check Out for Freight Rate!
