Standard Features
- ISO 9002 Certified
- Large 1 9/16" beam opening, adjustable
- 1" beam adjustment (front & back)
- Stop rods for repeat bends
- All steel heavy body construction with extra heavy tie rod
fro minimum deflection
- One year warrant on parts
|
|
Specifications |
|
Model |
SB-412 |
SB-612 |
| Bending
capacity in mild steel |
12 gauge |
12 gauge |
| Bending
length capacity |
4’ |
6’ |
| Bending angle
, degree |
0-135 |
0-135 |
| Beam
adjustment, front and back |
1” |
1” |
| Minimum
reverse bend |
5/16” |
5/16” |
| Manual
clamping |
standard |
standard |
| Beam opening
|
1 9/16” |
1 9/16” |
| Net weight,
approx |
1,310 LBS |
2,120 LBS |
| Dimensions,
approx |
72x35x41” |
98x35x41” |
|
|
|
