Standard Features
- ISO 9002 Certified
- Large 1 9/16" beam opening, adjustable
- 1" beam adjustment (front & back)
- Stop rids for repeat bends
- All steel heavy duty construction with extra heavy tie rod
fro minimum deflection
- One year warranty on parts
|
|
Specifications |
| Models |
SB-812HD |
SB-1014HD |
| Bending capacity in mild steel |
12 gauge |
14 gauge |
| Bending
length capacity |
8’ |
10’ |
| Bending angle
, degree |
0-135 |
0-135 |
| Beam
adjustment, front and back |
1” |
1” |
| Minimum
reverse bend |
5/16” |
5/16” |
| Manual
clamping |
standard |
standard |
| Beam opening
|
2 1/8” |
2 1/8” |
| Net weight,
LBS |
3,350 |
3,750 |
| Dimensions,
inch |
147x35x42” |
147x35x42” |
|
|
|
