Standard Features
- ISO 9002 Certified
- Large 1 9/16" beam opening, adjustable
- Standard 2", 3", 4", 5", & 6" wide fingers
- Stop rods for repeat bends
- All steel heavy body construction with extra heavy tie rid for minimum
deflection
- One year warranty on parts
|
|
Specifications |
| Model |
BB-412-6HD |
BB-612-6HD |
| Bending capacity
in mild steel
Bending |
12 Guage |
12 Guage |
|
Max. box depth |
5-1/2” |
5-1/2” |
|
Bending length capacity |
4’ |
6’ |
|
Bending angle , degree |
0-135 |
0-135 |
|
Beam adjustment, front and b |
1” |
1” |
|
Minimum reverse bend |
1/2” |
1/2” |
|
Manual clamping |
standard |
standard |
|
Beam opening |
1-9/16” |
1-9/16" |
|
Net weight, LBS |
1,410 LBS |
2,275 LBS |
|
Dimensions, inch |
72x35x45" |
98x35x45” |
|
|
|
