Specifications |
| Performance Data |
|
Standby Output KW (KVA) |
110 (137) |
|
Prime Output KW (KVA) |
100 (125) |
|
Generator RPM |
Revolving field, self-ventilated, dip proof |
|
Voltage - 3 phase |
Revolving field, self-ventilated, dip proof |
| Frequency |
60 Hz |
|
Sound Level dB(A) - full load 23 feet |
62 |
|
Amps - Single Phase 120V |
277.8A (4 wire), 301Ax2 (zigzag) |
|
Amps - Single Phase 240V |
138.9 (4 wire), 301A
(zigzag) |
| Amps - Three Phase - 240V |
301A |
|
Amps - Three Phase - 480V |
150A |
|
No. of Poles |
4 |
| Excitation |
Brushless w/ AVR |
|
Voltage - Single Phase |
120, 127, 139, 240, 254, 277V switchable |
|
Armature Connection |
Star w/ neutral/zigzaz |
|
Voltage Regulation - no load to full load |
1% |
|
Power Factor |
0.8 |
|
Generator Design |
Revolving field, self-ventilated, dip proof |
|
Frequency Regulation - no load to full load |
0.25% |
| Power Source |
|
Displacement cu. in (cc) |
6,800 cc |
|
Bore x Stroke (mm) |
106 x 127 |
|
Fuel Consumption - full load - gph (lph) |
7.7 (29) |
|
Fuel Consumption - 3/4 load - gph (lph) |
5.8 (21.9) |
|
Fuel Consumption - 1/2 load - gph (lph) |
3.8 (14.5) |
|
Fuel Consumption - 1/4 load - gph (lph) |
2.5 (9.3) |
|
Engine Coolant Capacity - gal (liters) |
4.43 (16.8) |
|
Fuel Tank Capacity - gal (liters) |
169 (640) |
| Battery |
12V 128Ah |
|
Engine Design |
4-cycle, water-cooled, direct injection, turbo |
|
Engine Model |
6068TF275 |
|
Oil Capacity - gal (liters) |
5.25 (19.9) |
|
Engine Make |
John Deere |
|
Starting System |
Electric |
|
No. Cylinders |
6 |
|
Horsepower (HP) |
150 |
| Dimensions |
|
Overall Height - in. (cm) |
73 (186) |
|
Overall Length - in. (cm) |
49 (124) |
|
Overall Width - in. (cm) |
120 (305) |
|
Approx Net Wt. lb (kg) |
6,031 (2,735) |
