Specifications |
| Performance Data |
| Standby Output KW
(KVA): |
22
(27) |
| Prime Output KW
(KVA): |
20
(25) |
| Generator
RPM |
Revolving field,
self-ventilated, dip proof |
| Voltage - 3
phase |
Revolving field,
self-ventilated, dip proof |
| Frequency: |
60 Hz |
| Sound Level dB(A) - full
load 23 feet |
56 |
| Amps - Single Phase
120V |
55.6 (4 wire), 60Ax2
(zigzag) |
| Amps - Single Phase
240V: |
27.8A (4 wire), 60A
(zigzag) |
| Amps - Three Phase -
240V |
60A |
| Amps - Three Phase -
480V |
30A |
| No. of Poles |
4 |
| Excitation: |
Brushless, with
AVR |
| Voltage - Single
Phase: |
120, 127, 139, 240, 254,
277V switchable |
| Armature
Connection: |
Star w/
neutral/zigzag |
| Voltage Regulation - no
load to full load: |
1% |
| Power Factor |
0.8 |
| Generator
Design |
Revolving field,
self-ventilated, dip proof |
| Frequency Regulation -
no load to full load |
3%-5% |
| Power
Source |
| Displacement cu. in
(cc): |
2,179
cc |
| Bore x Stroke
(mm) |
85x96 |
| Fuel Consumption - full
load - gph (lph): |
1.44
(5.47) |
| Fuel Consumption - 3/4
load - gph (lph): |
1.05
(3.99) |
| Fuel Consumption - 1/2
load - gph (lph): |
0.74
(2.81) |
| Fuel Consumption - 1/4
load - gph (lph): |
0.45
(1.7) |
| Engine Coolant Capacity
- gal (liters) |
1.7
(6.4) |
| Fuel Tank Capacity - gal
(liters): |
41.7
(158) |
| Battery |
12V
53Ah |
| Engine
Design: |
4-cycle, water-cooled,
direct injection |
| Engine
Model: |
AA-4LE2 |
| Oil Capacity - gal
(liters): |
2.24
(8.5) |
| Engine Make: |
Isuzu |
| Starting
System: |
Electric |
| No.
Cylinders |
4 |
| Horsepower
(HP): |
31.9 |
| Dimensions |
| Overall Height - in.
(cm): |
50 (126)
|
| Overall Length - in.
(cm): |
70 (179)
|
| Overall Width - in.
(cm): |
31 (79)
|
| Approx Net Wt. lb (kg):
|
1,840
(835)
|
