Specifications |
| Performance
Data |
| Standby Output KW (KVA): |
352 KW (440 KVA) |
| Prime Output KW (KVA) |
320 KW (400 KVA) |
| Generator RPM |
1800 |
| Voltage - 3 phase |
208, 220, 240, 416, 440,
480V Reconnectable |
| Frequency |
60 Hz |
| Insulation |
Class FClass F |
| Sound Level dB(A) - full
load 23 feet |
69 |
| Amps - Single Phase 120V: |
888.9A (4 wire) |
| Amps - Single Phase 240V |
444.4A (4 wire) |
| Amps - Three Phase -
240V: |
962A |
| Amps - Three Phase -
480V: |
481A |
| No. of Poles: |
4-Pole |
| Excitation |
Brushless with AVR |
| Voltage - Single Phase: |
120, 127, 139, 240, 254,
277 Adjustable |
| Armature Connection: |
Star with neutral |
| Voltage Regulation - no
load to full load: |
+/- 1.5 percent |
| Power Factor: |
0.8 |
| Generator Design: |
Revolving Field,
Self-ventilated, Single Bearing |
| Power
Source |
| Displacement cu. in (cc): |
930 (15,240) |
| Bore x Stroke (mm): |
140 x 165 |
| Fuel Consumption - full
load - gph (lph): |
20.4 (77.2) |
| Fuel Consumption - 3/4
load - gph (lph): |
15.8 (59.8) |
| Fuel Consumption - 1/2
load - gph (lph): |
11.0 (41.6) |
| Fuel Consumption - 1/4
load - gph (lph): |
6.6 (25.0) |
| Engine Coolant Capacity -
gal (liters): |
16.9 (64.0) |
| Fuel Tank Capacity - gal
(liters): |
129.5 (490) |
| Battery: |
12V 200Ah x 2 24V System |
| Engine Design: |
Direct injection,
Turbocharged, Aftercooled |
| Engine Model: |
SA6D140AE |
| Engine HP; rpm: |
478 |
| Oil Capacity - gal
(liters): |
19.5 (73.8) |
| Engine Make: |
Komatsu |
| Starting System: |
Electric |
| Dimensions |
| Overall Height - in.
(cm): |
83 (211) |
| Overall Length - in.
(cm): |
166 (422) |
| Overall Width - in. (cm): |
56 (142) |
| Approx Net Wt. lb (kg): |
11,950 (5420) |
| Generator
Accessories |
| Automatic Start/Stop
Control |
Standard |
| Electronic Governor
Control (Crystal Sync): |
Standard |
| Battery Charger |
Option |
| Engine Pre-Heater: |
Option |
