Specifications |
| Performance
Data |
| Standby Output KW (KVA): |
704 KW (880 KVA) |
| Prime Output KW (KVA): |
640 KW (800 KVA) |
| Generator RPM: |
1800 |
| Voltage - 3 phase: |
208, 220, 240, 416, 440,
480 Reconnectable |
| Frequency: |
60 Hz |
| Insulation: |
Class F |
| Sound Level dB(A) - full
load 23 feet: |
73 |
| Amps - Single Phase 120V: |
1777.8A (4 wire) |
| Amps - Single Phase 240V: |
888.9A (4 wire) |
| Amps - Three Phase - 240V |
1924A |
| Amps - Three Phase -
480V: |
962A |
| No. of Poles: |
4-Pole |
| Excitation |
Brushless with AVR |
| Voltage - Single Phase: |
120, 127, 139, 240, 254,
277 Adjustable |
| Armature Connection: |
Star with neutral |
| Voltage Regulation - no
load to full load: |
+/- 1 percent |
| Power Factor: |
0.8 |
| Generator Design: |
Revolving Field,
Self-ventilated, Single Bearing |
| Power
Source |
| Displacement cu. in (cc): |
1860 (30,480) |
| Bore x Stroke (mm): |
140 x 165 |
| Fuel Consumption - full
load - gph (lph): |
43.7 (165.4) |
| Fuel Consumption - 3/4
load - gph (lph): |
33.0 (124.9) |
| Fuel Consumption - 1/2
load - gph (lph): |
24.0 (90.9) |
| Fuel Consumption - 1/4
load - gph (lph): |
14.9 (56.4 |
| Engine Coolant Capacity -
gal (liters): |
42.3 (160.1) |
| Fuel Tank Capacity - gal
(liters): |
129.5 (490) |
| Battery: |
12V 200Ah x 4 24V System |
| Engine Design: |
Direct injection,
Turbocharged, Aftercooled |
| Engine Model: |
SA12V140 |
| Engine HP; rpm: |
980 |
| Oil Capacity - gal
(liters): |
39.9 (151.0) |
| Engine Make: |
Komatsu |
| Starting System |
Electric |
| No. Cylinders: |
12 |
| Dimensions |
| Overall Height - in.
(cm): |
99 (251) |
| Overall Length - in.
(cm): |
241 (612) |
| Overall Width - in. (cm): |
77 (196) |
| Approx Net Wt. lb (kg): |
24,692 (11,200) |
| Generator
Accessories |
| Automatic Start/Stop
Control: |
Standard |
| Electronic Governor
Control (Crystal Sync): |
Standard |
| Battery Charger: |
Option |
| Engine Pre-Heater: |
Option |
