SPECIFICATIONS |
COOLING
CAPACITY |
BTU/hr @ 95 F at 60%RH |
120,000 (10 TONS) |
COMPRESSOR
DATA |
Compressor
Type |
Hermetic Recip. |
Operating
Temperatures |
60-110 F .50%RH |
Non-CFC Refrigerant Charge
(Lbs.) |
407C |
|
Specifications |
Fan Data Evaporator |
Fan Type (Centrifigul) |
Belt Drive |
Air Flow (CFM) |
1800/3800 |
Supply Air Chute Data |
2-12"Dia.x30"Length |
Supply Air Chute Max. Length |
65 |
Motor HP |
3 |
Water Flow Data |
Flow Regulation Valve |
AUTOMATIC |
Inlet Water 85F-95F Exit(GPM) |
30 |
Inlet Water 75F-95F Exit(GPM) |
15 |
Inlet Water 65F-95F Exit(GPM) |
10 |
Inlet Water 55F-95F Exit(GPM) |
7.5 |
2 Separate Cooling Loops |
2 Inlets & 2 Outlets |
Electrical Data |
Power Supply (Volts) |
208/230-3 Phase |
Current Consumption (Amps) |
40.9/45.5 |
Power Consumption (KW) |
16.3 |
Maximum Circuit Breaker (Amps) |
60 at 208-V/50 at 230-V |
Minimum Circuit Ampacity (Amps) |
69.7 |
Min/Max Voltage |
195-225/210-250 |
Power Cord Gauge/Length |
8AWG/10 |
Plug Configruation |
FIELD SUPPLIED |
Dimensional Data Unitary Models |
Width x Depth x Height (Inches) |
32.25X44X68.5 |
Weight (Lbs.) |
750 |
Shipping Weight (Lbs.) |
825 |
Safety Device Data |
Compressor Overload |
INTERNAL |
Fan Motor Overload |
AUTOMATIC INTERNAL |
Evaporator Freeze-up |
HOT GAS BYPASS |
High Pressure Switch |
MANUAL |
Low Pressure Switch |
AUTOMATIC |
Compressor Short Cycle |
YES |
Automatic Restart |
YES |
Thermostat |
MICROPROCESSOR/DIGITAL |
Condensate Pump w 20' Head Pres. |
YES |
Condensate Pump Overflow |
YES |
Condensate Tank Overflow |
YES |
|
|
