Key Features
Tooling & Accessory Options
|
New
Features For 2008
-
Electric
Stroke Control Standard
(Value $996)
- New Power Unit Design
- New "Whisper Quiet" Hydraulic System
(patent pending)
- New Electronic Controls
- New Electric Foot Pedal
|
Limited Offer
FREE:
Punch & Die Starter Box-8 Sets:
3/16,5/16,7/16,9/16,11/16,13/16,15/16,1 1/16"
(VALUE $260.00)
 |
|
SPECIFICATIONS |
|
PUNCH |
US |
Metric |
| Max. Capacity |
1-1/2" dia. in 1" plate |
3.81cm x 2.54cm |
| Work Height |
36 5/8" |
93.02cm |
|
FLAT BAR SHEAR |
| Max. Width |
1/2" x 24" |
1.27cm x 60.96cm |
| Max. Thick. |
1" x 12" |
2.54cm x 30.48cm |
| Max. Round |
1 1/4" |
3.17cm |
| Max. Square |
1 1/4" |
3.17cm |
| Work Height |
33 3/4" |
85.72cm |
|
ANGLE SHEAR |
| Max. Size |
6" x 6" x 1/2" |
15.24cm x 15.24cm x 1.27cm |
| Work Height |
40" |
101.6cm |
|
COPER / NOTCHER |
| Max. Capacity |
3" x 6" x 1/2" |
7.62cm x 15.24cm x 1.27cm |
| Work Height |
40" |
101.6cm |
|
OPEN CAVITY |
| Specifications |
11-3/4" wide x 9" tall |
29.845cm x 22.86cm |
| Work Height |
51 3/4" |
131.445cm |
|
GENERAL SPECS |
| Rated Capacity |
120 ton |
| Throat Depth |
11" |
27.94cm |
| Open Height |
9-1/8" |
23.17cm |
| Shut Height |
7 |
17.78cm |
| Stroke |
2 1/2" |
6.35cm |
| Electric Motor Standard |
10 HP, 3 Phase, 208/240
v, 1725 rpm, 26 amp |
| Electric Motor
Options |
10 HP,
3 Phase, 440/480 v or 575 v, 13 amp, 10 HP, 1 Phase, 230 v, 40
amp |
| Hydraulic Pump Size |
24 gpm - stage |
90.84L per min |
| Valve Pressure |
4500 psi |
310.26bar |
| Reservoir |
17 gallons |
64L |
| Cylinder |
2 3/4" Ram |
6.98cm |
| Dimensions: Base x Height |
60" x 60" x 84" |
152.4cm x 152.4cm x 213.36cm |
| Shipping Weight |
5500 pounds |
2494.75kg |
|
|
EDWIW-120-04-1PH
$2,300.00
3 Phase to 1 Phase conversion for 120 Ton 'Jaws V' Ironworker, :::: Must be purchased with ironworker, Factory Install Only!
|
EDW120-56
$940.00
"10" Brake w/4-way Die-1/16", 1/8",3/16",1/4"- 10" (for use with IW-120-04) E2((Southern-Tool: FREE FREIGHT When Purchased With Edwards Ironworker))"
Click here for more information!!!
|
|
|
|
|
|
|
|
|
|
|
|
|
EDW0900-KIT
$165.00
3/8” x 12” x 16” punch Gauging Table Kit ----> Southern-Tool: FREE FREIGHT When Purchased With Edwards Ironworker
Click here for more information!!!
|
EDW0900-KIT-HD
$550.00
1” x 12” x 16” punch Heavy Duty Gauging table accessory kit ----> Southern-Tool: FREE FREIGHT When Purchased With Edwards Ironworker
Click here for more information!!!
|
EDW1017
$35.00
Fabricator’s Protractor guides your work to the shear or punch stations through 180 degrees ----> Southern-Tool: FREE FREIGHT When Purchased With Edwards Ironworker
Click here for more information!!!
|
