Baileigh Heavy Duty Hydraulic Shears

SH-5203HD 52 in - 3GA Heavy Duty Hydraulic Shear

SH-5208HD 52 in - 8GA Heavy Duty Hydraulic Shear

SH-5210-HD 52 in x 10GA Heavy Duty Hydraulic Shear

SH-8010-HD 80 in - 10GA Heavy Duty Hydraulic Shear
SH-5203HD 52 in - 3GA
Heavy Duty Hydraulic Shear
SH-5208HD 52 in - 8GA
Heavy Duty Hydraulic Shear
SH-5210-HD 52 in x 10GA
Heavy Duty Hydraulic Shear
SH-8010-HD 80 in - 10GA
Heavy Duty Hydraulic Shear

SH-70250-HD 96 in - 1/4 Heavy Duty Hydraulic Shear

SH-120250-HD 120 LENGTH, 1/4 MILD STEEL CAPACITY. SH-120500-HD 120 in - 1/2
SH-70250-HD 96 in - 1/4
Heavy Duty Hydraulic Shear
SH-120250-HD 120 in - 1/4
Heavy Duty Hydraulic Shear
SH-120500-HD 120 in - 1/2
Heavy Duty Hydraulic Shear




Models
SH-5203-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 3 (1/4) GAUGE MILD STEEL CAPACITY
SH-5203-HD-NC 220 VOLT THREE PHASE HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 3 (1/4) GAUGE MILD STEEL CAPACITY NUMERICALLY CONTROLLED
SH-5208-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 8 GAUGE MILD STEEL CAPACITY
SH-5210-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 10 GAUGE MILD STEEL CAPACITY.
SH-8010-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 80 LENGTH 10 GAUGE MILD STEEL CAPACITY.
SH-70250-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 96 LEGTH, 1/4 MILD STEEL CAPACITY.
SH-120250-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 120 LENGTH, 1/4 MILD STEEL CAPACITY.
SH-120500-HD 220 VOLT 3 PH HEAVY DUTY HYDRAULIC SHEAR. 120 LENGTH, 1/2 MILD STEEL CAPACITY.



Hydraulic Sheet Metal Shear SH-5203-HD

Hydraulic Sheet Metal Shear SH-5203-HD

Made in Taiwan

The SH-5203-HD from Baileigh Industrial is a heavy duty shear that can take anything you can throw at it.  The industrial grade hydraulic system is designed to shear up to 1/4 inch mild steel over its whole length of 52 inch.  Designed like the rest of the Baileigh Industrial shear line the SH-5203-HD uses only the best components and building practices to ensure a machine that will outlast you.  The frame is made from fully welded plate steel for increased rigidity and prolonged blade life.  Blades can be flipped and sharpened many times saving you money.

Operation of the SH-5203-HD is very simple, just push the foot pedal and the hydraulic hold downs grab the material to ensure a straight cut.  The blade drops and shears the material.   A control panels allows for rake adjustment, jog/run/stop controls, production counter, and much more. This Heavy duty shear can be run in the jog mode, single cycle mode, or continuous cycling mode.  There is also an easy to use adjustable blade gap lever that can be changed in seconds when changing thickness.  A convenient shadow line position rounds out the feature of the SH-5203-HD.

For more information on the SH-5203-HD heavy duty shear contact a representative today.



Specifications SH-5203-HD
Model SH-5203-HD
Back Gauge Length 23.62 inch
Shear Length 52 inch
Motor 15 hp
Thickness Ss 1/4 inch (7 ga.)
Strokes Per Minute 16 - 24
Front Gauge Length 39.37 inch
Blade Angle 1/2 - 2 degree Adjustable
Blade Gap Adjustment Manual, Lever Acuated
Power 220V / 3-phase
Shipping Weight 5,720 lbs.
Shipping Dimensions 91 x 54 x 65 inch
specifications subject to change without notice
Heavy Duty Metal Cutting Shear SH-5203-HD-NC

SH-5203-HD-NC Heavy Duty Metal Cutting Shear

Built for years of heavy cutting, this numerically controlled shear makes industrial production runs more efficient. Blade gap and rake angle adjustment ensure high cut quality.

Features:
  • Cuts up to 52 inch-wide sheet metal.
  • Maximum capacity of 1/4 inch mild steel.
  • 15 hp motor runs on 220-volt 3-phase power.
  • Upper blade carriage that rides in a 3-axis bearing housing.
  • Heavy-duty precision ground and hardened rail system gives you unbeatable accuracy and long blade life.
  • Front and rear supports and side guides help you keep material square to the blade.
  • Roller infeed table makes it easy to maneuver heavy plate steel for the next cut.
  • 8 hydraulic hold-downs provide 3.2 tons of pressure each, preventing sheet metal from lifting.
  • Programmable quick-change backgauge rides on a screwball rail system with a positioning encoder.
  • Switch between 3 modes as needed:
    • Jog mode: Inching the blade down to the material.
    • Single cycle mode: One cut for one pedal push.
    • Automatic cycling mode: Continuously cutting for production runs.
  • Piece counter makes it simpler to do production runs.
  • Remote operator control pendant houses an E-Stop button and foot pedal controls.
  • Simple handle lets you adjust the blade gap in seconds to avoid crimping or folding, particularly with thinner material.
  • Adjustable rake angle can change for your material thickness, giving you cleaner cuts and reducing strain on the hydraulics.
  • It’s simple to set the rake angle: just hit a button, move the lever, and a light goes on when you reach the correct angle.
  • High carbon chromium blades that have several edges (2 on top, 4 on bottom), so you can flip them several times before you need to resharpening.
  • Shadow light stretches the entire length of the web width for proper placement of the beginning of the cut, for those one-off shearing requirements.
  • Fully welded plate steel framework maintains stability, reduces flex, and minimizes burr.
  • Covered by a 1-year parts warranty.
  • We stock blades and replacement parts at our Wisconsin warehouse; we can ship them out quickly
Specifications SH-5203-HD-NC
Item Number SH-5203-HD-NC
Motor Hp 15
Blade Rake Angle .5 to 2.0 degrees
Back Gauge Length 23.62 inch
Shear Length 52 inch
Strokes Per Minute 30 - 42
Front Gauge Length 39.37 inch
Blade Angle 2-Jan
Blade Gap Adjustment Manual, Lever Acuated
Power 220V / 3-phase
Shipping Weight 5820lbs
Minimum Material Thickness 24ga
Shipping Dimensions (Inches) 90x73x68



Hydraulic Metal Shear SH-5208-HD

Hydraulic Metal Shear SH-5208-HD

Made in Taiwan

At 28 strokes per minute the SH-5208-HD hydraulic metal cutting shear is truly a workhorse that you must have in your shop.  The SH-5208-HD has a shearing capacity of 8 gauge (11/64 inch) mild steel over its entire length of 52 inch, making it perfect for these 4x8 ft sheets of metal that are commonly found at steel suppliers.

The SH-5208-HD is built for heavy duty production, this machine has thick steel plate frame that is fully welded for rigidity.  The shearing carriage rides against hardened carriage ways and uses heavy duty bearings to reduce friction and wear. The industrial grade hydraulics system on the SH-5208-HD is powered by a 10 hp 220 volt three phase motor.

Operation of the SH-5208-HD is easy; the centralized control panel offers the selection of jog, single or continuous cutting modes.  A showdown line helps to line up the next cut for accuracy.  There is also a dial for adjusting the rake that eliminates curl and twist in cutting as well as a quick adjustment lever for material thickness.  The upper blade is two sided while the lower blade is four sided. The blades can be resharpened when needed saving money.  A back gauge, roller tables and side gauges round out this great package.

For more information on the SH-5208-HD Hydraulic metal cutting shear, contact a representative today.

Specifications
Model SH-5208-HD
Back Gauge Length 23.62 inch
Shear Length 52 inch
Motor 10 hp
Thickness Ss 8 ga. (12 ga.)
Strokes Per Minute 30 - 42
Front Gauge Length 39.37 inch
Blade Angle 1/2 - 2 degree Adjustable
Blade Gap Adjustment Manual, Lever Acuated
Power 220V / 3-phase
Shipping Weight 4,400 lbs.
Shipping Dimensions 91 x 48 x 63 inch
specifications subject to change without notice



Heavy Duty Hydraulic Sheet Metal Shear SH-5210-HD

Heavy Duty Hydraulic Sheet Metal Shear SH-5210-HD

Made in Taiwan

The SH-5210-HD heavy duty hydraulic shear is a heavy duty machine built for years of production. It will take what you can throw at it and keep coming back for more.  This machine has thick steel plate frame that is fully welded for rigidity.  The shearing carriage rides against hardened carriage ways and uses heavy duty bearings to reduce friction and wear. The industrial grade hydraulics system on the SH-5210-HD is powered by a 7.5 hp 220 volt three phase motor.

The centralized control panel offers the selection of jog, single or continuous cutting modes. There is also a dial for adjusting the rake that eliminates curl and twist in cutting as well as a quick adjustment lever for material thickness.  The upper blade is two sided while the lower blade is four sided. The blades can be resharpened when needed saving money.

This hydraulic sheet metal cutting shear has rigid, heavy duty load table and side gauges.  A light shadow line for shearing position is standard and st the rear of the machine is a manual back gauge for repeatability.  For more information on the SH-5210-HD heavy duty hydraulic shear, contact a representative today.



Specifications
Model SH-5210-HD
Back Gauge Length 23.62 inch
Shear Length 52 inch
Motor 7.5 hp
Thickness Ss 10 ga. (13 ga.)
Strokes Per Minute 35 - 47
Front Gauge Length 39.37 inch
Blade Angle 1/2 - 2 degree Adjustable
Blade Gap Adjustment Manual, Lever Acuated
Power 220V / 3-phase
Shipping Weight 3,960 lbs.
Shipping Dimensions 91 x 48 x 63 inch
specifications subject to change without notice



shear

The SH-70250-HD from Baileigh Industrial is a hydraulic shear that cuts 1/4 inch mild steel over its entire 70 inch length.  The frame of the SH-70250-HD is all integrated and fully welded to eliminate vibrations commonly found on other models.  By eliminating vibrations, it is eliminating any strees that can occur during the cutting process.

The SH-70250-HD features an NC controller for programming of the back gauge.  This programmer is accurate to =/- .01mm and can hold up to 100 programs.  Convenient rolling tables mounted on the front of the machine help with loading of materials.  Gap is easily adjusted via hand wheels.

Since the SH-70250-HD hydraulic shear is built to last, Baileigh Industrial uses only the best quality components, Schneider electrical, Rexroth hydraulic systems, and NOK seals from Japan.

Specifications
Model SH-70250-HD
Thickness (mild steel) .250 inch
Max. Material Thickness (Stainless Steel) .177 inch
Blade Rake Angle 1.5 degree
Blade Clearance Manual Hand Wheel
Back Gauge Length 23.62 inch
Shear Length 70.8 inch
Motor 10 hp
Power 220V / 3-phase
Shipping Weight 6,500 lbs.
Shipping Dimensions 95 x 57 x 73 inch
specifications subject to change without notice



Heavy Duty Hydraulic Sheet Metal Shear SH-8010-HD

Heavy Duty Hydraulic Sheet Metal Shear SH-8010-HD

Made in Taiwan

Have a lot of production to do and like the idea of a heavy duty shear that can take anything you can throw at it?  Then the Sh-8010-HD might just be the shear for you.  Running on a powerful 7.5 hp 220 volt three phase motor, the SH-8010-HD hydraulic sheet metal shear is capable of cutting a piece of 10 gauge mild steel that is 80 inch wide.  Thirteen powerful hold downs clamp the material securely so there is no material lift when the cut is being made, helping to prolong blade life. Like all other Baileigh Industrial shears this machine is built using heavy steel plate that is fully welded to offer the any shop years of service. The shearing blades also have multiple cutting edges allowing for longer blade life.

To help load material, front support rails have scales on them and the shearing table has integrated rollers so the material slides easier.   The SH-8010-HD has a manual back gauge to help make the cut more accurate.  A shadow line positioner is another way to ensure accuracy on the SH-8010-HD.  The SH-8010-HD can be operated in the jog, single cycle, or continuous cycle mode when the foot pedal is pressed.

Contact a representative for more information on the hydraulic sheet metal shear line.



Specifications
Model SH-8010-HD
Back Gauge Length 23.62 inch
Shear Length 80 inch
Motor 7.5 hp
Thickness Ss 10 ga. (13 ga.)
Strokes Per Minute 32 - 44
Front Gauge Length 39.37 inch
Blade Angle 1/2 - 2 degree Adjustable
Blade Gap Adjustment Manual, Lever Acuated
Power 220V / 3-phase
Shipping Weight 6,600 lbs.
Shipping Dimensions 119 x 48 x 65 inch
specifications subject to change without notice



Hydraulic Metal Shear, SH-10010

Plate Shear SH-120250-HD

At 18 strokes a minute the SH-120250-HD shear cutting machine from Baileigh Industrial is a must have in any production environment that shears 1/4 inch mild steel.  The SH-120250-HD plate shear can cut 1/4 inch mild steel over its entire 120 inch length.  For even more production the SH-120250-HD features an NC controller for programming of the back gauge.  This programmer is accurate to =/- .01mm and can hold up to 100 programs.  Convenient rolling tables mounted on the front of the machine help with loading of materials.  Gap is easily adjusted via hand wheels.  Another nice feature is the shadow line postioner to help with placement of material.

Since the SH-120250-HD hydraulic sheet metal shear is built to last, Baileigh Industrial uses only the best quality components, Schneider electrical, Rexroth hydraulic systems, and NOK seals from Japan.  The massive frame of the SH-120250-HD is all integrated and fully welded to eliminate vibrations commonly found on other models.  By eliminating vibrations, it is eliminating any stress that can occur during the cutting process.

For more information on the SH-120250-HD, contact a representative today.

Specifications
Model SH-120250-HD
Thickness (mild steel) .250 inch
Max. Material Thickness (Stainless Steel) .125 inch
Blade Rake Angle .5 to 1.5 Degrees
Blade Clearance Manual Hand Wheel
Back Gauge Length 25.6 inch Motorized
Shear Length 120 inch
Motor 15 hp
Strokes Per Minute 15
Power 220V 3-Phase / 60 Hertz
Shipping Weight 14000lbs
Minimum Material Thickness 18ga.
Shipping Dimensions (Inches) 164x80x74 & 69x48x9
specifications subject to change without notice



Sheet Metal Shear SH-12010

Three Phase Heavy Duty Hydraulic Shear SH-120500-HD

When cutting 1/2 inch mild steel plate, you need a machine that is built to last and perform day in any day out.  The SH-120500-HD is just that machine.  This massive machine weighs in at just over 23,000 lbs and features a frame that is all integrated and fully welded to eliminate vibrations commonly found on other models.  By eliminating vibrations, it is eliminating any stress that can occur during the cutting process. The SH-120500-HD heavy duty metal shear uses only the best quality components, Schneider electrical, Rexroth hydraulic systems, and NOK seals from Japan.  Running a shear of this size is not easy, but the SH-120500-HD has a large 20 hp motor that runs on 220 volt three phase.

At 9 strokes a minute for a 10’ plate of 1/2 inch mild steel the SH-120500-HD from Baileigh Industrial is great in any production environment that shears 1/2 inch thick steel.  For even more production the SH-120500-HD features an NC controller for programming of the back gauge.  This programmer is accurate to =/- .01mm and can hold up to 100 programs.  Convenient rolling tables mounted on the front of the machine help with loading of materials.  Gap is easily adjusted via hand wheels.  Another nice feature is the shadow line postioner to help with placement of material.

For more information on the SH-120500-HD heavy duty metal shear, contact a representative today.



Specifications
Model SH-120500-HD
Thickness (mild steel) .50"
Max. Material Thickness (Stainless Steel) .250"
Blade Rake Angle .5 to 2.0 degrees
Blade Clearance Manual Hand Wheel
Back Gauge Length 31.5" Motoroized
Shear Length 120"
Motor 30 hp.
Strokes Per Minute 9
Power 220V / 3-phase
Shipping Weight 23750lbs
Squaring Arm Length 48" (Can be used on right or left side, includes 4 bump stops)
Minimum Material Thickness 18ga
Shipping Dimensions (Inches) 158x88x100 & 69x46x9
specifications subject to change without notice



There are no listed accessories.

BA9-1007087
SH-5203-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 3 (1/4) GAUGE MILD STEEL CAPACITY **SHIPS FLAT-BED FREIGHT TRUCK, WGT = 5820 LBS & MADE IN TAIWAN

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007087
BAISH-5203-HD
lease to own for as little as:$732 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$38,159.00

96
BA9-1007095
SH-5203-HD-NC; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 3 (1/4) GAUGE MILD STEEL CAPACITY **SHIPS FLAT-BED FREIGHT TRUCK, WGT = 5820 LBS & MADE IN TAIWAN

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007095
BAISH-5203-H{00
lease to own for as little as:$862 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$45,619.00

96
BA9-1007099
SH-5208-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 8 GAUGE MILD STEEL CAPACITY **SHIPS LTL FREIGHT TURCK, WGT = 4400 LBS & MADE IN TAIWAN

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007099
BAISH-5208-HD
lease to own for as little as:$627 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$33,359.00

96
BA9-1007122
SH-5210-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 52 LENGTH 10 GAUGE MILD STEEL CAPACITY **SHIPS LTL FREIGHT TURCK, WGT = 4200 LBS & MADE IN TAIWAN

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007122
BAISH-5210-HD
lease to own for as little as:$566 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$29,839.00

96
BA9-1007202
SH-8010-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 80 LENGTH 10 GAUGE MILD STEEL CAPACITY **SHIPS FLAT-BED FREIGHT TRUCK, WGT = 6600 LBS & MADE IN TAIWAN

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007202
BAISH-8010-HD
lease to own for as little as:$778 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$40,839.00

96
BA9-1007179
SH-70250-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 96 LEGTH, 1/4 MILD STEEL CAPACITY **SHIPS FLAT-BED FREIGHT TRUCK, WGT = 10525 LBS & MADE IN CHINA

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007179
BAISH-70250-HD
lease to own for as little as:$932 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$49,629.00

96
BA9-1007078
SH-120250-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 120 LENGTH, 1/4 MILD STEEL CAPACITY **SHIPS FLAT-BED FREIGHT TRUCK, WGT = 13500 LBS & MADE IN CHINA

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007078
BAISH-120250-HD
lease to own for as little as:$1,022 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$54,749.00

96
BA9-1007085
SH-120500-HD; 220V 3PHASE HEAVY DUTY HYDRAULIC SHEAR. 120 LENGTH, 1/2 MILD STEEL CAPACITY **SHIPS FLAT-BED FREIGHT TRUCK, WGT = 21000 LBS & MADE IN CHINA

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1007085
BAISH-120500-HD
lease to own for as little as:$1,464 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$79,989.00

96
Copyright © 2024 Smith-Hamilton, Inc
0.008 240404 15:03
