Baileigh Woodworking Drill Presses



sliding table saw sliding table saw cnc
Sliding Table Saw STS-14120
CNC Table Saw STS-14120-CNC
CNC Table Saw STS-14120-CNC



drill press

Bench Top Drill Press DP-1512B

1002987

The DP-1512B 15 inch bench top drill press from Baileigh Industrial is a great drill press for any shop with limited floor space.  This compact drill press is only about 35 inch tall and is best suited when mounted to a bench and still has all the features of its bigger brother the DP-1512F including its large 15 inch swing and cast iron 12 by 12 inch table.  The table also incorporates a rack and pinion system for raising and lowering.  A large 3 inch spindle diameter makes for a rigid platform.

This 110 volt bench top drill press has 12 spindle speeds that range from 250 to 3600 rpm.  A range that is broad enough for just about any project.   The spindle stroke for the DP-1512B is a full 3 inch and uses an industry standard MT2 spindle taper.   The DP-1512B also includes a drill chuck with a maximum capacity of 5/8 inch.  For more information on this or any of the other Baileigh Industrial drill presses, contact a representative today.


Specifications
Model DP-1512B-HD
Table Size (Length) 12 inch
Table Size (Width) 12 inch
Swing 15 inch
Drill Capacity .7 inch
Tailstock MT2
Spindle Travel 3.1 inch
Column Diameter 2.8 inch
Power 110V
Length 36 inch
Width 20 inch
Height 40 inch
Horse Power 3/4 HP
Weight (lbs) 134

specifications subject to change without notice

drill press

15 inch Drill Press DP-1512F-HD

1002988

The DP-1512F floor mounted 15 inch drill press is a great choice for anyone that is looking for an economical belt driven drill press. The DP-1512F has 12 spindle speeds that range from 250 to 3600 rpm and is only powered by 110 volts, making it perfect for just about any shop.  It features an MT2 spindle taper and includes a chuck with a maximum capacity of 5/8 inch.  It also has a full 3 inch of spindle stroke.

The DP-1512F includes a large 15 inch swing and cast iron 12 inch by 12 inch table with an integrated rack and pinion system for making raising and lowering a breeze.   A large 3 inch column diameter combined with a cast iron 19 x 11.5 inch base makes for a rigid platform.     For more information on this or any of the other Baileigh Industrial drill presses, contact a representative today.






Specifications
Model DP-1512F-HD
Table Size (Length) 12 inch
Table Size (Width) 12 inch
Swing 15 inch
Spindle MT2
Drill Capacity 0.7 inch
Spindle Travel 3.1 inch
Column Diameter 2.8 inch
Power 110V
Length 36 inch
Width 20 inch
Height 64 inch
Horse Power 0.5
Weight (lbs) 148

specifications subject to change without notice

drill press

Floor Drill Press DP-2012F-HD-V2

1014890

Need more capacity from your drill press, well look at the DP-2012F-HD-V2 floor drill press to see if it will fit your needs.  This mammoth has a 20 inch swing and a cast iron 16.5 x 18.5 inch oversized table and can handle just about anything that you can throw at it.  The 3.6 inch diameter column and 24 x 16.5 inch cast iron base make for one rigid structure.

The DP-2012F-HD-V2 uses 110 volts to turn its MT4 spindle to 3200 rpms.  The range of speeds is done through the use of six pulleys that give the DP-2012F 12 spindle speeds.  It also includes a drill chuck that can opens to a maximum of 3/4 inch.  For more information on the DP-2012F-HD-V2 or any of the other Baileigh Industrial floor drill presses call and speak to a representative today



Specifications
Model - 110V - 1 Ph - 60 Hz DP-2012F-HD
Model - 220V - 1 Ph - 60 Hz DP-2012F-HD
Spindle Speeds 12 - 220 to 3200 rpm
Distance from spindle to table 26 inch
Distance from spindle to base 46.75 inch
Table Size (Length) 16.5 inch
Table Size (Width) 18.5 inch
Swing 20 inch
Spindle MT4
Drill Capacity 1.25 inch
Rpm 150-4200
Spindle Travel 4.75 inch
Drill Chuck Capacity 1/32 - 5/8 inch (JT3 key)
T Slot Size 3 at 5/8 inch
Length 35.4 inch
Width 25.6 inch
Height 66.7 inch
Horse Power 2 hp
Weight (lbs) 259

specifications subject to change without notice



drill press

Drill Press DP-15VSF

1002989

Made in Taiwan

The DP-15VSF is the ultimate woodworking drill press.  This belt driven variable speed drill press has a true 1 hp motor that runs off of 110 volts, but can be wired to run on 220 volt single phase should the need arise.  The availability of variable speed lets the MT2 spindle on the DP-15VSF turn at any speed from 400 to 5000 rpm, perfect for the wood worker.  A digital readout helps determine the operating speed. a 6” spindle stroke.

Built to last the DP-15VSF has a large 3 inch diameter column that allows for 15 inches of swing.   For those larger projects it has a 14 x 18 inch table with 5/8 inch t-slots.  The table also incorporates a rack and pinion system for moving the table up and down.  A halogen work light and drill chuck round out this great variable speed drill press package.



Specifications
Model DP-15VSF
Spindle Travel 6 inch
Shipping Weight 300 lbs.
Table Size (Length) 14 inch
Table Size (Width) 18 inch
Swing 15 inch
Spindle MT2
Drill Capacity .625 inch
Spindle Travel 6 inch
Power 110V
Length 30 inch
Width 20 inch
Height 71 inch
Horse Power 1
Weight (lbs) 300

specifications subject to change without notice

There are no listed accessories.

BA9-1012078
DP-1512B-HD; 110V 15 BENCH TOP DRILL PRESS, 550-2500 RPM, 12 ROUND TABLE **SHIPS LTL FREIGHT TRUCK, WGT = 170 LBS & MADE IN CHINA
Mfg. item #: BA9-1012078
BAIDP-1512B-HD
See freight charges if any at checkout. ALWAYS FREE Residential and Liftgate when Requested.1054
$726.99

86
BA9-1012079
DP-1512F-HD; 110V 15 FLOOR DRILL PRESS 550-2500 RPM, 12 ROUND TABLE, MALTA2 SPINDLE TAPER **SHIPS LTL FREIGHT TURCK, WGT = 250 LBS & MADE IN CHINA

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1012079
BAIDP-1512F-HD
See freight charges if any at checkout. ALWAYS FREE Residential and Liftgate when Requested.1055
$813.99

86
BA9-1015771
220V 20 FLOOR DRILL PRESS 12 SPINDLE SPEEDS, 16.5X18.5 TABLE MT4, LED WORKLIGHT / MADE IN CHINA / WGT = 390 LBS / SHIPS LTL TRUCK FREIGHT (SKU 1015771)ADD TO CART NOW FOR FREE SHIPPING ANYWHERE IN THE LOWER 48 STATES
Mfg. item #: BA9-1015771
BAIDP-2012F-HD
FREE expedited shipping Plus FREE residential, liftgate and call ahead service. 4
$1,657.00

228
BA9-1002989
DP-15VSF; 110/220V SINGLE PHASE (PREWIRED 110) 15 VARIABLE SPEED FLOOR DRILL PRESS **SHIPS LTL FREIGHT TURCK, WGT = 400 LBS & MADE IN TAIWAN

CALL 800-458-3687 OR ADD TO CART FOR THE BEST BROTHER-IN-LAW DEAL ON THIS BAILEIGH ITEM ALSO FREE LTL FREIGHT,& FREE RESIDENTIAL, LIFTGATE AND DELIVERY APPOITMENT SERVICES AND NO HANDLING FEE
Mfg. item #: BA9-1002989
BAIDP-15VSF
lease to own for as little as:$54 per month!
Free freight for Jet-Powermatic-Wilton orders over $1,500. ALWAYS FREE Residential and Liftgate when Requested.1057
$2,728.00

86
