DAKE Tire Presses



33-587 Air Powered Tire Press, 150-ton	33-493 Electric Powered Tire Press, 150-ton	33-672 Electric Powered Tire Press, 150-ton w/ Gaurding

Click image to enlarge

At a Glance
33-587
33-493
33-672

TIRE PRESSES
933493	33-493	Electric Powered Tire Press, 150-ton , 220/440-3 ph
933672	33-672	Electric Powered Tire Press, 150-ton w/ Gaurding, 220/440-3 ph
933587	33-587	Air Powered Tire Press, 150-ton

Air Powered Tire Press Model 33-587 150 tons Capacity

Air operated tire press with 150 ton capacity for handling large tires. Removes tires from wheels quickly and easily. Upper movable head channel provides 15 inch of travel for easy set-up. Easily removable pins allow head channel to be set in four different positions.

Features:

150 ton capacity for handling large tires
Upper movable head channel provides 15â³ of travel for easy set-up
Pressing rings in diameters and face widths for all standard tire sizes
Large 7-3/4 inch ram provides platen stability and longer seal life
Removable pins allow head channel to be set in four different positions
Eliminates outside servicing delays and truck downtime

Standard Equipment

Steel Frame
Removable Table Pins
Upper Movable Head Channels
Self-Locking Hoist
Pressure Gauge

Model Options

Larger Capacities
Additional Ram Stroke
Special Frame Sizes
Different Size Pressing Rings

Specifications
Model Number	33-587
Part Number	33-587
Capacity	150 tons
Voltage	n/a
Horsepower	n/a
Ram Speed Advance	1-1/2 in/min
Ram Speed Return	Gravity
Width Between Uprights	36 inch
Maximum Daylight	30 inch
Stroke	n/a
Ram Travel	12 inch
Head Channel Travel	15 inch
Platen Diameter	25 inch
Overall Height	80 inch
Floor Space	66 inch x 42 inch
Weight	3,350 lbs

Electric Tire Presses Model 33-493 150 tons Capacity

Electric Tire Presses Model Model 33-493 150 tons Capacity

Electrically operated tire press with 150 ton capacity for handling large tires. Removes tired from wheels quickly and easily. Upper movable head channel provides 15â³ of travel for easy set-up. Easily removable pins allow head channel to be set in four different positions.

Features:

150 ton capacity for handling large tires
Upper movable head channel provides 15â³ of travel for easy set-up
Pressing rings in diameters and face widths for all standard tire sizes
Large 7-3/4â³ ram provides platen stability and longer seal life
Removable pins allow head channel to be set in four different positions
Eliminates outside servicing delays and truck downtime

Standard Equipment

Steel Frame
Removable Table Pins
Upper Movable Head Channels
Self-Locking Hoist
Pressure Gauge

Model Options

Larger Capacities
Additional Ram Stroke
Special Frame Sizes
Different Size Pressing Rings

Specifications
Model Number	33-493
Part Number	933493
Capacity	150 tons
Voltage	220/440 V, 3-Phase
Horsepower	10 HP
Ram Speed Advance	2-3/4 in/min
Ram Speed Return	Gravity
Width Between Uprights	36 inch
Maximum Daylight	30 inch
Stroke	n/a
Ram Travel	12 inch
Head Channel Travel	15 inch
Platen Diameter	25 inch
Overall Height	80 inch
Floor Space	57 inch x 43 inch
Weight	3,000 lbs

Electric Tire Presses Model 33-672 150 Tons Capacity

Electrically operated tire press with 150 ton capacity for handling large tires. Removes tires from wheels quickly and easily. Additional guarding for safety, faster ram speed, and an 18â³ stroke.

Features:

150-ton capacity for handling large fork lift tires
Large 7-3/4 inch ram provides platen stability and longer seal life.
Upper movable head channel provides 15 inch of travel for easy set-up
Removable pins allow head channel to be set in four different positions.
Eliminates outside servicing delays and truck downtime
Expanded metal guard with larger 1 inch opening
18 inch Stroke, 17 inch IPM speed

Standard Equipment

Steel Frame
Removable Table Pins
Upper Movable Head Channel
Self-Locking Hoist
Metal Guarding
Pressure Gauge

Model Options

Larger Capacities
Additional Ram Stroke
Special Frame Sizes
Different Size Pressing Rings

Specifications
Model Number	33-672	33-493
Part Number	933672	933493
Capacity	150 Tons	150 tons
Voltage	220/440 V, 3-Phase	220/440 V, 3-Phase
Horsepower	10 HP	10 HP
Ram Speed Advance	17 in/min	2-3/4 in/min
Ram Speed Return	Gravity	Gravity
Width Between Uprights	36 inch	36 inch
Maximum Daylight	36 inch	30 inch
Stroke	18 inch	n/a
Ram Travel	18 inch w/ limit switch	12 inch
Head Channel Travel	15 inch	15 inch
Platen Diameter	25 inch	25 inch
Overall Height	80 inch	80 inch
Floor Space	57 inch x 43 inch	57 inch x 43 inch
Weight	3,600 lbs	3,000 lbs

Compare

MODEL 33-493 - ELECTRIC POWERED TIR

Mfg. item #: 933493

DAKE933493

Call for freight quote on this item or we will confirm freight charges before shipping.¹

Call for Price

1073

Compare

MODEL 33-672 - ELECTRIC POWERED TIR

Mfg. item #: 933672

DAKE933672

Call for freight quote on this item or we will confirm freight charges before shipping.¹

Call for Price

1087

Compare

DAKE MODEL 33-587 - AIR POWERED TIRE PRESS, 150-TON

Mfg. item #: 933587

DAKE933587

Call for freight quote on this item or we will confirm freight charges before shipping.¹

Call for Price

607
