WET DUST COLLECTORS use a water filled tank through which all grinding dust is pulled by a motor driven impeller fan. Particles sink to the base of the tank where they can easily be removed by raking into a provided container. Normal tap water is used, there are no filter bags to be changed. Water level is automatically controlled when unit is connected to a water supply. All units are equipped with explosion relief door and sound silencer.
|Max. Part Width||40 in|
|Abrasive Belt Size||40-1/2 in x 75 in|
|Passline Height||34 in - 37 in|
|Max. Thickness Capacity||3-1/8 in|
|Conveyor Drive Speeds||8-40 FPM|
|Infeed Conveyor Length||20 in|
|Dust Collector Capacity||1,800 CFM|
|Main Motor||15 HP, 230V / 460V, 3-Ph|
|Conveyor Motor||1.5 HP, 230V / 460V,3-Ph|
|Table Lifting Motor||1 HP, 230V / 460V, 3-Ph|
|Net Weight, approx.||4,650 LBS|
|Machine Dimensions, LxWxH||76 x 88 x 81 in|
One Year Industrial Parts Warranty
Mfg. item #: FP-4075
lease to own for as little as:$359 per month!
Call for freight quote on this item or we will confirm freight charges before shipping.1
Call for price. GMCHDDP-4075
Mfg. item #: WDC-FP40
lease to own for as little as:$138 per month!
Add to Equipment listed above for Free Freight or flat shipping rate of $10.00 within the Lower 48 States30
