Features
Lightweight, industrial puller is perfect for rigging, stretching, pulling and positioning loads
Gradual slip clutch mechanism provides automatic overload protection by disengaging handle during overload
Automatic overload protection provides maximum operator safety
Shock resistant gear case and brake cover
Safe, trouble-free mechanical brake is designed to avoid seizing and is asbestos-free
Powder coat pained prior to assembly to protect against abrasion, rust and corrosion
Completely portable for indoor or outdoor use
Chain stopper indicates lowering limit to protect the body
Lever features rubber grip to ensure safe and easy operation
Top and bottom safety hooks are standard.
Meets OSHA and AMSE/ANSI B30.21 and HST-3M standards
Proof tested and certified
SPECIFICATIONS | ||||||
Model | JTP-75-5 | JTP-75-15 | JTP-150-5 | JTP-150-15 | JTP-300-5 | JTP-300-15 |
Capacity (ton) | 3/4 | 3/4 | 1 1/2 | 1 1/2 | 3 | 3 |
Headroom (in) | 12 7/16 | 12 7/16 | 14 | 14 | 19 3/4 | 19 3/4 |
Length (in) | 14.9 | 14.9 | 20.4 | 20.4 | 21.8 | 21.9 |
Height (in) | 6.5 | 6.6 | 6.5 | 6.4 | 8.6 | 8.6 |
Width (in) | 6.3 | 6.5 | 8 | 8.3 | 9.4 | 9 |
Lever length (in) | 10 1/4 | 10 1/4 | 16 1/8 | 16 1/8 | 16 1/8 | 16 1/8 |
Lift per full turn of handle (in) | 3/4 | 3/4 | 7/8 | 7/8 | 5/8 | 5/8 |
Load chain (dia./mm) | 6 | 6 | 8 | 8 | 10 | 10 |
Number of falls | 1 | 1 | 1 | 1 | 1 | 1 |
Rated capacity (lbs) | 1,653 | 1,653 | 3,307 | 3,307 | 6,614 | 6,614 |
Required lbs of pull to lift capacity | 32 | 32 | 42 | 42 | 72 | 72 |
Standard lift (ft) | 5 | 15 | 5 | 15 | 5 | 15 |
Volume (cf) | 0.4 | 0.4 | 0.6 | 0.6 | 1 | 0.9 |
Ship weight (lbs) | 16.75 | 22.4 | 28.8 | 38.45 | 47.5 | 63.05 |
Net weight (lbs) | 16.75 | 22.4 | 28.8 | 38.45 | 47.5 | 63.05 |
Gross weight (lbs) | 16.75 | 22.4 | 28.8 | 38.45 | 47.5 | 63.05 |
CAUTION: Be sure supporting structures and load-attaching devices used in conjunction with this puller provide an adequate safety factor to handle the rated load plus the weight of the equipment. If in doubt, consult a qualified structural engineer. This equipment is not to be used for lifting, supporting or transporting people, or lifting or supporting load over people.
IMPORTANT: Before installation, read owner¹s manual for additional warnings and precautions. Not for use in explosive environment.
NOTE: Custom lifts available in any length. However, custom lift pullers are not returnable
