Laguna Bandsaws

laguna 14|12 12 inch RESAW 110V - 1.75 HP - 1 Hz laguna 14|BX 12 inch RESAW 110V - 1.75 HP - 1 Hz laguna 14|BX 12 inch RESAW 220V - 2.5 HP - 1 Hz 18|BX 16 inch RESAW 220V - 3 HP - 1 Hz
 1412 BANDSAW
38in Table Height, Tension Indicator, 110 Volt Outlet
 14BX BANDSAW
38in Table Height, Disc-Brake with Micro-Switch, 110V or 220V Motor Available
 18BX BANDSAW
3HP, 220V Motor, 145in Blade Length, 18in Throat
 18CX BANDSAW
Designed For Both Wood and Metal, 1.75 HP, 110V Motor, 16in Resaw Height Capacity



Models
MBAND1412-175  14|12 12 inch RESAW
MBAND14BX110-175 14|BX 12 inch RESAW
MBAND14BX220-250 14|BX 12 inch RESAW
MBAND18BX2203 18|BX 16 inch RESAW
MBAND18CX110175 18|CX 16 inch RESAW
Accessories
MBA14/12WHEELSYSTEM WHEEL SYSTEM FITS 14|12 and 14|BX and REVO 12|16
MBA18BX-CX-WS WHEEL SYSTEM FITS 18|BX and 18|CX
ALEDMACH LED LIGHT DOUBLE ARM ADJUSTABLE BRIGHTNESS and COLOR, ALLOY HEAD
ALEDSPINE LED LIGHT 20 inch FLEX SPINE
ALEDLATHE LED LIGHT DOUBLE ARM ADJUSTABLE BRIGHTNESS & COLOR, RECTANGULAR HEAD
ALAREVO18LIGHT HALOGEN LIGHT DOUBLE ARM
MBA14BX-LIGHT220-DA HALOGEN LIGHT DOUBLE ARM
MBA14/12LIGHT HALOGEN LIGHT SHORT ARM
ABMG001 MINI GUIDES
ABMG002 REPLACEMENT PHENOLIC INSERTS SET
AB10PCKIT1418BX 10PC CERAMIC W/ GLUE 14|12, 14|BX, 18|BX
AB100 CERAMIC RECTANGULAR FITS HD
AB1001 CERAMIC RECTANGULAR FITS 14|12, 14SUV, 18 3000
AB1005 CERAMIC ROUND FITS 14|12, 3000, HD
AB00003A COOL BLOCK SET 3000 SERIES
AB000031 COOL BLOCK SET16 HD and LARGER
AB000041 LAGUNA GUIDES FITS MOST EURO
14|12 Bandsaw

1412 Bandsaw

Click here to download manual

The 1412 Bandsaw is a 110 Volt saw that feels like a 220. Features include pyramid shaped spine, 1 3/4 HP TEFC Motor, quick release tension, 115 volt outlet and micro polished 21 x 16 inch table mounted onto oversized Trunion paired with Aluminum Hi/Low Fence. Solid Cast Wheels are electronically, dynamically balanced and fitted with polyurethane one-piece tires designed to run cooler and last longer than conventional tires. The worm gear and pinion is ultra-smooth and engineered to have minimum flex even when fully extended. This is a trade mark of Laguna, just like the famous ceramic Laguna guides. Double windows allows you to check both tension and tracking while the machine is running.

Shown With Optional Wheel and Light Systems

Blade Not Included

Specifications:

  • Laguna Guides
  • 4 inch Dust Port
  • Table Height 38 inch
  • 110 Volt Outlet
  • Tension Window
  • Tension Indicator
  • Tracking Window
  • Cast Iron Wheels
  • Table Tilt Right: 45 deg
  • Table Tilt Left: 7 deg
  • Positive Stop: 90 deg
  • Table Size: 21-1/2 x 16 in
  • Quick-Release Tension
  • Rack and Pinion Upper Guide
  • Heavy Duty Cast Trunion: 8 x 13 in
  • Included: 6ft Cord With Plug
  • Nema: 5-15P
  • Premium Anodized Aluminum Throat Plate
  • Hi/Low Aluminum Fence: 18 x 5-1/2 x 1/2 in
  • Dual Voltage Motor: 115/230, Pre-Wired 115 Volt
  • Motor: 14/7 Amp TEFC
  • HP: 1-3/4 - 115/230V
  • Safety Key
  • 12 in Resaw
  • Stand Included
  • Blade Length: 115 in
  • Min Blade Width: 1/8 in
  • Max Blade Width: 3/4 in
  • Illuminated On/Off Switch
  • Shipping Weight: 350lbs
  • Shipping Dimensions (L x W x H): 55in x 22in x 25in





14|bx Bandsaw 110 Volt

14BX Bandsaw

Click here to download manual

Main differences from 1412:

  • Weight increased
  • Solid one-piece Frame
  • Frame is heavier Gauge
  • Magnetic On/Off Switch
  • Disc-Brake w/ Micro-Switch
  • Dual light mounting positions

Shown with optional Blade

THIS MACHINE SOLD EXCLUSIVELY THROUGH OUR DEALER NETWORK

110Volt:

  • 1.75 HP, 14 Amp, TEFC
  • 110 Volt Outlet for Light
  • 6 ft. Cord w/ Nema Plug: 5-15P
  • Weight (Net/Ship): 260/320 Lbs.

220Volt:

  • 1 Phase, 2.5HP, 9.8Amp, TEFC
  • 220 Volt Outlet for Light
  • 6 ft. Cord w/Nema Plug: 6-15P
  • Weight (Net/Ship): 270/330 Lbs

Specifications:

  • 12 inch Resaw
  • Height: 70-1/4 inch
  • 21-1/2 x 16 inch Table
  • Table Height: 38 inch
  • 7 deg Table Tilt Left
  • 45 deg Table Tilt Right
  • 2 X 4 inch Dust Ports
  • Blade Length: 115 inch
  • Cast Iron Wheels
  • Magnetic Starter
  • Dual Light Mount
  • Max. Blade Width: 3/4 inch
  • Pyramid-Shaped Spine
  • Min. Blade Width: 1/8 inch
  • Footprint: 17-1/2 x  22-1/2 inch
  • Quick Release Tension
  • Magnetic Blade Guard
  • Laguna Ceramic Guides
  • Hi/Low aluminum Fence
  • Worm Gear Rack and Pinion
  • Massive Cast Trunion 8 x 13 inch
  • Shipping Weight 350 lbs
  • Shipping Dimensions (LxWxH) 73x27x29 inch





18|bx Bandsaw 220V 3HP

18BX Bandsaw

Click here to download manual

The 18BX Bandsaw follows in the traditions of high-performance and reliability established by the widely-used Laguna Tools 1412 and 14bx models. The 18bx is built around a 3HP, 220V motor and 145 inch (368 cm) blade for consistent results, cut-after-cut, regardless of wood material.

Shown with optional Blade, Lighting and Mobility Kit

THIS MACHINE SOLD EXCLUSIVELY THROUGH OUR DEALER NETWORK

Blade Not Included

Features:

  • Motor: 3HP, 220V, 1 Ph. 12 Amp.
  • Recommended Breaker: 20 Amp.
  • Magnetic Starter
  • Min-Max Blade Width: 1/8 -1 1/4 in
  • Resaw Capacity: 16 in
  • Throat: 18 in
  • Blade Length: 145 in
  • Disc-Brake With Micro Switch
  • 220V Outlet On Back For Light
  • Window For Tension
  • Window For Tracking
  • Magnetic Blade Tension Guide
  • Worm Gear and Pinion Upper Guide
  • 10 Point Laguna Ceramic Guides
  • Flat Poly-Groove Drive Belt
  • Premium Anodized Insert With Micro Adjustment
  • Dynamically Balanced Cast Iron Wheels
  • Urethane Single Piece Snap-On Tire
  • Cast Table Size: 20 x 26 in
  • Table Tilt: -6, +45 deg
  • Cast Table Size: 20 x 26 in
  • Table Tilt: -6, +45 deg
  • Quick-Release Tension
  • Hi/Low Anodized Aluminum Fence: 22-1/2 x 5-3/4 x 1/2 in
  • Table Height: 38 in
  • Dust Ports: 4in x 2
  • Overall Height: 77-3/4 in
  • Dimensions (Base): 27″ x 20 in
  • Dimensions Overall: 36″ x 30 in
  • Dimensions Box: 82″ x 34″ x 24 in
  • Weight (Net/Ship): 410/460 lbs
  • Shipping Weight: 490lbs
  • Shipping Dimensions (L x W x H): 55in x 22in x 25in





18|CX Bandsaw

18|CX Bandsaw

The 18|CX Bandsaw follows in the traditions of high-performance and reliability to be expected from a Laguna Tools Bandsaw. The 18|CX is built with a 1.75HP, 110V motor and features variable speed control to cut through metals with ease.

THIS MACHINE SOLD EXCLUSIVELY THROUGH OUR DEALER NETWORK

Blade Not Included

Features:

  • Motor: 1.75HP, 100V, 14/7 Amp.
  • Recommended Breaker: 20 Amp.
  • Magnetic Starter
  • Min-Max Blade Width: 1/8 to 1-1/4 inch
  • Resaw Capacity: 16 inch
  • Throat: 18-7/32 inch
  • Blade Length: 145 inch
  • Disc-Brake with Micro Switch
  • 110V Outlet on Back for Light
  • Window for Tension
  • Window for Tracking
  • Magnetic Blade Tension Guide
  • Worm Gear and Pinion Upper Guide
  • 10 Point Laguna Ceramic Guides
  • Mechanical Variable Speed Drive
  • Low Blade Speed: 100-290 FPM
  • High Blade Speed: 1200-3500 FPM
  • Anodized Insert w/Micro Adjustment
  • Dynamically Balanced Cast Iron Wheels
  • Urethane Single Piece Snap-on Tire
  • Cast Table Size: 20 x 26 inch
  • Table Tilt: - 6 deg, + 45 deg
  • Quick-Release Tension
  • Hi/Low Anodized Aluminum Fence: 22-3/4 x 7-1/4 x 11/16 inch
  • Table Height: 38 inch
  • Dust Ports: 2 x 4 inch
  • Overall Height: 77-3/4 inch
  • Dimensions, Base: 27 x 20 inch
  • Dimensions Overall: 38 x 36 inch
  • Dimensions Box: 82 x 34 x 36 inch
  • Weight (Net/Ship): 480/545 Lbs.
  • Shipping Weight 420 lbs
  • Shipping Dimensions (LxWxH) 55 x 22 x 25 in



Call for price. LAGMBAND1412-175
MBAND14BX110-17
14|BX 12 RESAW - BANDSAW - 110V / 1.75 HP
Mfg. item #: MBAND14BX110-17
LAGMBAND14BX{00
$99.00 Freight Rate for Laguna and Supermax machines. Any accessory added to this order ships free - Includes FREE Residential, FREE Liftgate & Call Ahead Service1049
$1,499.00

24
MBAND14BX220-25
14|BX 12 RESAW - BANDSAW - 220V / 2.5 HP / 1PHASE
Mfg. item #: MBAND14BX220-25
LAGMBAND14BX{01
$99.00 Freight Rate for Laguna and Supermax machines. Any accessory added to this order ships free - Includes FREE Residential, FREE Liftgate & Call Ahead Service1049
$1,499.00

24
MBAND18BX2203
18|BX 16 RESAW - BANDSAW - 220V / 3 HP / 1PHASE
Mfg. item #: MBAND18BX2203
LAGMBAND18BX{00
$99.00 Freight Rate for Laguna and Supermax machines. Any accessory added to this order ships free - Includes FREE Residential, FREE Liftgate & Call Ahead Service1049
$1,999.00

24
MBAND18CX110175
18|CX 16 RESAW - BANDSAW - 110V / 1.75 HP
Mfg. item #: MBAND18CX110175
LAGMBAND18CX{00
lease to own for as little as:$60 per month!
$99.00 Freight Rate for Laguna and Supermax machines. Any accessory added to this order ships free - Includes FREE Residential, FREE Liftgate & Call Ahead Service1049
$2,999.00

24
MBA14/12WHEELSY
REVO 12|16: WHEEL SYSTEM (LATHE ACCESSORY)
Mfg. item #: MBA14/12WHEELSY
LAGMBA14/12W{00
FREE shipping when ordered with a machine from this manufacturer.20
$150.00

24   1
MBA18BX-CX-WS
WHEEL SYSTEM FITS 18|BX & 18|CX (BANDSAW ACCESSORY)
Mfg. item #: MBA18BX-CX-WS
LAGMBA18BX-C{00
FREE shipping when ordered with a machine from this manufacturer.20
$175.00

24
ALEDMACH
LED DOUBLE ARM ADJUSTABLE BRIGHTNESS & COLOR, ALLOY HEAD, 110V LIGHT (LED WORK LIGHTS)
Mfg. item #: ALEDMACH
LAGALEDMACH
FREE shipping when ordered with a machine from this manufacturer.20
NEW ITEM
$150.00

24
ALEDSPINE
LED FLEX SPINE 110V LIGHT (LED WORK LIGHTS)
Mfg. item #: ALEDSPINE
LAGALEDSPINE
FREE shipping when ordered with a machine from this manufacturer.20
NEW ITEM
$90.00

24
ALEDLATHE
LED DOUBLE ARM ADJUSTABLE BRIGHTNESS & COLOR 110V LIGHT (LED WORK LIGHTS)
Mfg. item #: ALEDLATHE
LAGALEDLATHE
FREE shipping when ordered with a machine from this manufacturer.20
NEW ITEM
$150.00

24
ALAREVO18LIGHT
HALOGEN LIGHT DOUBLE ARM 110V (LATHE ACCESSORY)
Mfg. item #: ALAREVO18LIGHT
LAGALAREVO18{0A
FREE shipping when ordered with a machine from this manufacturer.20
$150.00

24
MBA14BX-LIGHT22
HALOGEN LIGHT DOUBLE ARM 220V (LATHE ACCESSORY)
Mfg. item #: MBA14BX-LIGHT22
LAGMBA14BX-L{00
FREE shipping when ordered with a machine from this manufacturer.20
$150.00

24
MBA14/12LIGHT
HALOGEN LIGHT SHORT ARM (BANDSAW ACCESSORY) 110V
Mfg. item #: MBA14/12LIGHT
LAGMBA14/12L{00
FREE shipping when ordered with a machine from this manufacturer.20
$99.00

24
ABMG001
MINI GUIDES (BANDSAW ACCESSORY)
Mfg. item #: ABMG001
LAGABMG001
FREE shipping when ordered with a machine from this manufacturer.20
$150.00

24
ABMG002
REPLACEMENT PHENOLIC INSERTS SET (BANDSAW ACCESSORY)
Mfg. item #: ABMG002
LAGABMG002
FREE shipping when ordered with a machine from this manufacturer.20
$50.00

24
AB10PCKIT1418BX
10PC CERAMIC W/ GLUE 14|12, 14|BX, 18|BX (BANDSAW ACCESSORY)
Mfg. item #: AB10PCKIT1418BX
LAGAB10PCKIT{00
FREE shipping when ordered with a machine from this manufacturer.20
$99.00

24
AB100
CERAMIC RECTANGULAR FITS HD (BANDSAW ACCESSORY)
Mfg. item #: AB100
LAGAB100
FREE shipping when ordered with a machine from this manufacturer.20
$10.00

24
AB1001
CERAMIC RECTANGULAR FITS 14|12, 14SUV, 18 3000 (BANDSAW ACCESSORY)
Mfg. item #: AB1001
LAGAB1001
FREE shipping when ordered with a machine from this manufacturer.20
$10.00

24
AB1005
CERAMIC ROUND FITS 14|12, 3000, HD (BANDSAW ACCESSORY)
Mfg. item #: AB1005
LAGAB1005
FREE shipping when ordered with a machine from this manufacturer.20
$10.00

24
AB00003A
COOL BLOCK SET 3000 SERIES (BANDSAW ACCESSORY)
Mfg. item #: AB00003A
LAGAB00003A
FREE shipping when ordered with a machine from this manufacturer.20
$150.00

24
AB000031
COOL BLOCK SET16 HD & LARGER (BANDSAW ACCESSORY)
Mfg. item #: AB000031
LAGAB000031
FREE shipping when ordered with a machine from this manufacturer.20
$175.00

24
AB000041
LAGUNA GUIDES FITS MOST EURO (BANDSAW ACCESSORY)
Mfg. item #: AB000041
LAGAB000041
FREE shipping when ordered with a machine from this manufacturer.20
$299.00

24
