Powermatic PM1800B, PM2013B, PM2415B 18, bandsaws

At Powermatic, we believe that ambition is the fuel that drives progress. Every product we engineer is born out of the same idea: How can we empower woodworkers to do more? In shops across the world, craftsmen are continually pushing the limits of their creativity, and in turn, challenging us to provide the best tools for the job. When we reimagined our line of bandsaws, we not only set out to meet their ambitions, but to exceed them. Larger projects and larger workpieces call for more power, more resaw capacity and more cast iron. This bandsaw also features the legendary quality, precision and attention to detail that has been helping woodworkers expand their ambition for more than ninety years

powermatic warranty 5 year

bandsaw

PM1800B, 18 inch Bandsaw, 5HP

Features:

  • Exclusive Powermatic T-Square style Accu-Fence maximizes accuracy and safety
  • The Accu-Fence has complete adjustability for aligning to blade and squaring to table
  • Sturdy cast iron table and trunnion assembly offers maximum rigidity for large work pieces
  • Positive locking cam with pressure adjustment
  • Oversized side plate can be used in the horizontal or vertical position
  • Solid steel resaw post for optimum rigidity
  • Blade tension release with electrical interlock prevents the bandsaw from starting when the blade is de-tensioned (patent pending)
  • Heavy duty upper wheel support and tracking mechanism for smooth operation
  • Solid cast iron upper and lower wheels create the momentum needed for heavy resaw
  • High end blade guides with tool less adjustment provide stability, increasing cut accuracy
  • Four sided blade guard for optimum protection
  • Integrated foot brake stops a coasting blade
  • Magnetic switch protects the motor from harm due to potential electrical supply issues
  • Heavy-duty 5 horsepower motor provides power needed for all projects
  • 460V operation requires an additional 460V magnetic switch part PM1800B-043C
SPECIFICATIONS
Model Number PM1800B PM1800B-3
Stock Number 1791800B 1791801B
Cutting Capacity Width (in.) 18 18
Cutting Capacity Height (in.) 18 18
Blade Length (in.) 160 160
Blade Speed (SFPM) 2300/4400 2300/4400
Maximum Saw Blade Width (in.) 1-1/2 1-1/2
Minimum Saw Blade Width (in.) 1/8 1/8
Table Size (L x W) (in.) 24 x 27 24 x 27
Table Tilt (deg.) 10 Left, 45 Right 10 Left, 45 Right
Table Height from Floor (in.) 38 38
Miter Gauge Positive Stops 45, 90 45, 90
Dust Collection Minimum CFM Required (CFM) 600 600
Dust Port Outside Diameter (in.) 4 4
Motor Current (Amps) 22 15/7.5
Motor Power (HP) 5 5
Motor Phase (PH) 1 3
Motor Voltage (V) 230 230/460
Prewired Voltage (V) 230 230
Overall Dimensions (L x W x H/in.) 38 x 42 x 81-1/2 38 x 42 x 81-1/2
Net Weight (lbs.) 840 834



PM2013B-3, 20" Bandsaw, 5HP 3PH 230/460V

PM2013B, 20 inch Bandsaw, 5HP

Features:

  • Exclusive Powermatic T-Square style Accu-Fence maximizes accuracy and safety
  • The Accu-Fence has complete adjustability for aligning to blade and squaring to table
  • Sturdy cast iron table and trunnion assembly offers maximum rigidity for large work pieces
  • Positive locking cam with pressure adjustment
  • Oversized side plate can be used in the horizontal or vertical position
  • Solid steel resaw post for optimum rigidity
  • Blade tension release with electrical interlock prevents the bandsaw from starting when the blade is de-tensioned (patent pending)
  • Heavy duty upper wheel support and tracking mechanism for smooth operation
  • Solid cast iron upper and lower wheels create the momentum needed for heavy resaw
  • High end blade guides with tool less adjustment provide stability, increasing cut accuracy
  • Four sided blade guard for optimum protection
  • Integrated foot brake stops a coasting blade
  • Magnetic switch protects the motor from harm due to potential electrical supply issues
  • Heavy-duty 5 horsepower motor provides power needed for all projects
  • 460V operation requires an additional 460V magnetic switch part PM1800B-043C
SPECIFICATIONS
Model Number PM2013B PM2013B-3
Stock Number 1791257B 1791258B
Cutting Capacity Width (in.) 20 20
Cutting Capacity Height (in.) 18 18
Blade Length (in.) 170 160
Blade Speed (SFPM) 2300/4400 2300/4400
Maximum Saw Blade Width (in.) 1-1/2 1-1/2
Minimum Saw Blade Width (in.) 1/4 1/8
Table Size (L x W) (in.) 24 x 27 24 x 27
Table Tilt (deg.) 10 Left, 45 Right 10 Left, 45 Right
Table Height from Floor (in.) 36 36
Miter Gauge Positive Stops 45, 90 45, 90
Dust Collection Minimum CFM Required (CFM) 600 600
Dust Port Outside Diameter (in.) 4 4
Motor Current (Amps) 22 15/7.5
Motor Power (HP) 5 5
Motor Phase (PH) 1 3
Motor Voltage (V) 230 230/460
Prewired Voltage (V) 230 230



PM2415B, 24" Bandsaw, 5HP

PM2415B, 24 inch Bandsaw, 5HP

Features:

  • Exclusive Powermatic T-Square style Accu-Fence maximizes accuracy and safety
  • The Accu-Fence has complete adjustability for aligning to blade and squaring to table
  • Sturdy cast iron table and trunnion assembly offers maximum rigidity for large work pieces
  • Positive locking cam with pressure adjustment
  • Oversized side plate can be used in the horizontal or vertical position
  • Solid steel resaw post for optimum rigidity
  • Blade tension release with electrical interlock prevents the bandsaw from starting when the blade is de-tensioned (patent pending)
  • Heavy duty upper wheel support and tracking mechanism for smooth operation
  • Solid cast iron upper and lower wheels create the momentum needed for heavy resaw
  • High end blade guides with tool less adjustment provide stability, increasing cut accuracy
  • Four sided blade guard for optimum protection
  • Integrated foot brake stops a coasting blade
  • Magnetic switch protects the motor from harm due to potential electrical supply issues
  • Heavy-duty 5 horsepower motor provides power needed for all projects
  • 460V operation requires an additional 460V magnetic switch part PM1800B-043C
SPECIFICATIONS
Model Number PM2415B PM2415B-3
Stock Number 1791259B 1791260B
Cutting Capacity Width (in.) 24 24
Cutting Capacity Height (in.) 15 15
Blade Length (in.) 183 183
Blade Speed (SFPM) 2500/4800 2500/4800
Maximum Saw Blade Width (in.) 1-1/2 1-1/2
Minimum Saw Blade Width (in.) 1/4 1/8
Table Size (L x W) (in.) 24 x 34 24 x 34
Table Tilt (deg.) 10 Left, 45 Right 10 Left, 45 Right
Table Height from Floor (in.) 35 35
Miter Gauge Positive Stops 45, 90 45, 90
Dust Collection Minimum CFM Required (CFM) 600 600
Dust Port Outside Diameter (in.) 4 4
Motor Current (Amps) 22 15/7.5
Motor Power (HP) 5 5
Motor Phase (PH) 1 3
Motor Voltage (V) 230 230/460
Prewired Voltage (V) 230 230



powermatic warranty 5 year WARRANTY AND SERVICE

WMH Tool Group, Inc., warrants every product it sells. If one of our tools needs service or repair, one of our Authorized Service Centers located throughout the United States can give you quick service. In most cases, any of these WMH Tool Group Authorized Service Centers can authorize warranty repair, assist you in obtaining parts, or perform routine maintenance and major repair on your POWERMATIC tools. For the name of an Authorized Service Center in your area call 1-800-274-6848.



Bandsaws
Stock Number Product Description
1791800B PM1800B Bandsaw 5HP, 1PH, 230V
1791801B PM1800B-3 Bandsaw 5HP, 3PH, 230/460V
1791257B PM2013B Bandsaw 5HP, 1PH, 230V
1791258B PM2013B-3 Bandsaw 5HP, 3PH, 230/460V
1791259B PM2415B Bandsaw 5HP, 1PH, 230V
1791260B PM2415B-3 Bandsaw 5HP, 3PH, 230/460V

s-h alt

Click here for Bandsaw Blades - We have been manufacturing Since 1926!

More Informationshow more
1791800B
>>PM1800B, 18 BANDSAW, 5HP 1PH 230V
CALL 1-800-458-3687 FOR OUR BROTHER-IN-LAW DEAL ON THIS ITEM
Mfg. item #: 1791800B
WMH1791800B
lease to own for as little as:$100 per month!
Limited time! FREE SHIPPING, FREE TAILGATE & RESIDENTIAL DELIVERIES on this and other JET, POWERMATIC, WILTON and PERFORMAX products ordered together.1020
$5,101.99

3
More Informationshow more
1791801B
>>PM1800B-3, 18 BANDSAW, 5HP 3PH 230/460V
CALL 1-800-458-3687 FOR OUR BROTHER-IN-LAW DEAL ON THIS ITEM
Mfg. item #: 1791801B
WMH1791801B
lease to own for as little as:$100 per month!
Limited time! FREE SHIPPING, FREE TAILGATE & RESIDENTIAL DELIVERIES on this and other JET, POWERMATIC, WILTON and PERFORMAX products ordered together.1020
$5,101.99

3
More Informationshow more
1791257B
>>PM2013B, 20 BANDSAW, 5HP 1PH 230V
CALL 1-800-458-3687 FOR OUR BROTHER-IN-LAW DEAL ON THIS ITEM
Mfg. item #: 1791257B
WMH1791257B
lease to own for as little as:$110 per month!
Limited time! FREE SHIPPING, FREE TAILGATE & RESIDENTIAL DELIVERIES on this and other JET, POWERMATIC, WILTON and PERFORMAX products ordered together.1020
$5,611.99

3
More Informationshow more
1791258B
>>PM2013B-3, 20 BANDSAW, 5HP 3PH 230/460V
CALL 1-800-458-3687 FOR OUR BROTHER-IN-LAW DEAL ON THIS ITEM
Mfg. item #: 1791258B
WMH1791258B
lease to own for as little as:$110 per month!
Limited time! FREE SHIPPING, FREE TAILGATE & RESIDENTIAL DELIVERIES on this and other JET, POWERMATIC, WILTON and PERFORMAX products ordered together.1020
$5,611.99

3
More Informationshow more
1791259B
>>PM2415B, 24 BANDSAW, 5HP 1PH 230V
CALL 1-800-458-3687 FOR OUR BROTHER-IN-LAW DEAL ON THIS ITEM
Mfg. item #: 1791259B
WMH1791259B
lease to own for as little as:$119 per month!
Limited time! FREE SHIPPING, FREE TAILGATE & RESIDENTIAL DELIVERIES on this and other JET, POWERMATIC, WILTON and PERFORMAX products ordered together.1020
$6,121.99

3
More Informationshow more
1791260B
>>PM2415B-3, 24 BANDSAW, 5HP 3PH 230/460V
CALL 1-800-458-3687 FOR OUR BROTHER-IN-LAW DEAL ON THIS ITEM
Mfg. item #: 1791260B
WMH1791260B
lease to own for as little as:$119 per month!
Limited time! FREE SHIPPING, FREE TAILGATE & RESIDENTIAL DELIVERIES on this and other JET, POWERMATIC, WILTON and PERFORMAX products ordered together.1020
$6,121.99

3
