Standard Equipment
Vibration drive via centrifugal
clutch
Water sprinkler system
Removable water tank
Fold-over steering handle
Scrapers front and rear
Support bars front and rear
Honda engine with oil alert
Optional Equipment
Special Paint
Compaction Output (yd3/h) at recommended soil layer thicknesses. | ||||
Model | Rock Fill | Gravel, Sand | Mixed Soil | Silt, Clay |
BPR45/55 |
- | 39-52 | 33-44 | 27-37 |
Note: The reference values in the above table are the result of compaction trials and practical applications. Under normal application conditions the required compaction values will be reached after four to eight passes. |
Earthworks |
||||||
# passes | Rolling Speed | Area Coverage | Productivity in cu yd/hr by lift thickness, 100% efficiency | |||
(mph) | sq yd/hr | 2 inch | 4 inch | 6 inch | 8 inch | |
2 | 1 | 538 | 30 | 60 | 90 | 120 |
3 | 1 | 359 | 20 | 40 | 60 | 80 |
4 | 1 | 269 | 15 | 30 | 45 | 60 |
5 | 1 | 215 | 12 | 24 | 36 | 48 |
Asphaltic Concrete (material weight 140 lbs/cu ft) |
||||||
# passes | Rolling Speed | Area Coverage | Productivity in tons/hr by lift thickness, 100% efficiency | |||
(mph) | sq yd/hr | 2 inch | 4 inch | 6 inch | 8 inch | |
2 | 1 | 538 | 42 | 57 | 71 | 85 |
3 | 1 | 359 | 28 | 38 | 47 | 57 |
4 | 1 | 269 | 21 | 28 | 35 | 42 |
5 | 1 | 215 | 17 | 23 | 28 | 34 |
6 | 1 | 179 | 14 | 19 | 24 | 28 |
Specifications |
|
Model | BW55E |
Weights |
|
Basic weight - lbs (kg) |
333 (151) |
Operating Weight CECE - lbs (kg) |
355 (161) |
Static linear load CECE - pli (kg/cm) |
16.2 (2.9) |
Dimensions |
|
Working width - in (mm) |
22 (560) |
Driving characteristics (depending on site conditions) |
|
Speed (1), forward/reverse - mph (kmph) |
0-0.7 (0-1.1) |
Speed (2), forward/reverse - mph (kmph) |
0-1 (0-1.6) |
Max. gradeability without/with vibration - % |
25/20 |
Drive |
|
Engine manufacturer |
Honda |
Type |
GX 120 K1 |
Cooling |
air |
Number of cylinders |
1 |
Performance ISO 9249 - hp (kW) |
3.0 (2.2) |
Speed |
2750 |
Performance SAE - hp (kW) |
3.0 (2.2) |
Speed - rpm |
2750 |
Fuel |
gasoline |
Starting device |
recoil |
Drive System |
mech |
Sprinkler System |
|
Type of sprinkler |
gravity |
Capacitie |
|
Fuel - gal (l) |
0.7 (2.5) |
Water - gal (l) |
4.2 (16) |
Engine Oil - gal (l) |
0.2 (0.6) |
Technical modifications reserved. Machine may be shown with options. |
Mfg. item #: BW55E
BOMBW55E
Call for freight quote on this item or we will confirm freight charges before shipping.1
Call for Price
