Mi-T-M 8 Gal Gasoline Single Stage Air C



Click image to enlarge



View Product Sheet

  • Compressor Pump: Quality cast iron single stage compressor, Stainless-steel braided discharge hose, Splash lubricated cast iron crankcase to extend the hours of performance, Cast iron head for heat dissipation, Large canister intake filter
  • Motor: Industrial UL-listed electric motor, Auto start/stop (continuous run optional), Thermal overload protection
  • Frame: Powder coated 8-gallon twin tank receivers, 3/16-inch base plate to reduce vibration, 14-gauge powder coated two-piece belt guard with 1/4-turn release for quick access to belts, Convenient lifting handles, Pneumatic tire with tube and steel hub
  • Components: Regulator and two gauges for tank and outlet pressure, Manual drain valves for proper maintenance, Industrial grade pressure switch, 10-inch flywheel for extra cooling and longer life, Belt tightening system pulls engine straight to ensure constant belt alignment
Specifications
Model AM1-PE15-08M
CFM @ 100 PSI 6.5
HP/Motor 1.5/120V, 13.2A Electric
Plug Type NEMA 5-15P
Net Weight 170 lbs.
Shipping Weight 190 lbs.
Length 44.5 in.
Width 18.5 in.
Height 25 in.

AM1-PE15-08M
Mfg. item #: AM1-PE15-08M
MTMAM1-PE15-08M
FREE motor freight to commercial address or terminal pickup in lower 48 states. Residential or Export Orders call 800-458-3687.11
$912.50
