Mi-T-M 8 Gal Gasoline Two Stage Air Comp


Click image to enlarge

At a Glance
Specifications
Options
Accessories

Compressor Pump: Quality cast iron two stage compressor with venting system for reduced crankcase temperature and pressure, Splash lubricated cast iron crankcase to extend the hours of performance, Cast iron head and cylinder for extended durability, Large canister intake filter, Stainless-steel braided discharge hose
Engine: Industrial Honda OHV engine (electric start optional), Engine oil drain, Pneumatic idle control to conserve fuel
Frame: Powder coated ASME coded 20-gallon receiver tank, 3/16-inch base plate to reduce vibration, 14-gauge powder coated two-piece belt guard with 1/4-turn release for quick access to belts
Components: Regulator and two gauges for tank and outlet pressure, 16.5-inch fly wheel for extra cooling and longer life, Manual drain valves for proper maintenance, Belt tightening system pulls engine straight to ensure constant belt alignment, Quality pilot valve unloader

Specifications
Model	AM2-SH09-20M
CFM @ 100 PSI	17.2
Displacement/Engine	270cc Honda OHV
Bolt Down Dimensions (LxW)	23.193in. x 11in.
Net Weight	306 lbs.
Shipping Weight	356 lbs.
Length	37 in.
Width	18 in.
Height	38 in.

AX-0003	Manual drain metal bowl
AX-0015	Electric start (battery and cables not included)
AX-0017	Electric start (battery and cables included)

Air Compressor Accessories
	10-inch Puncture-Proof Tires
	3/8-inch Filter/Regulator AT-4011-M
	Air Chucks
	Air Filter Canisters
	Air Filter Elements
	Air Hoses
	Air/Water Adapter Kit
	Blow Guns
	Brass Fittings
	Coupler Test Bar
	Couplers
	Couplers/Plug Sets
	Electric Compressor Drain
	Engine Oil Drain Kits
	Filters
	Gauges
	In-Line Lubricators
	Leader Hose
	Plugs
	Regulators
	Replacement Pumps
	Steel Hex Nipples

Compare

AIR COMPRESSOR 20 GAL

Mfg. item #: AM2-SH09-20M

MTMAM2-SH09-20M

Call for freight quote on this item or we will confirm freight charges before shipping.¹

$2,067.62

104

Compare

OPTION-MANUAL DRAIN METAL BOWL

Mfg. item #: AX-0003

MTMAX-0003

FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.²⁰

$277.36

104

Compare

OPTION-8HP HONDA ELEC START

Mfg. item #: AX-0015

MTMAX-0015

FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.²⁰

$479.55

110

Compare

OPTION-BATTERY/TRAY/BOX/CABLES

Mfg. item #: AX-0017

MTMAX-0017

FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.²⁰

$259.90

104 1

Freight policies for items on this page:

1: Call for freight quote on this item or we will confirm freight charges before shipping.

20: FREE shipping ONLY when ordered with a machine from this manufacturer otherwise Ground UPS Will Be Added at Order Entry.

Free freight offers apply only to deliveries to the lower 48 states by truck freight or ground UPS. Liftgate and non-commercial delivery charges may be extra.
