Baileigh Tube Bender Layout Software

Our tube bending software (program) helps the fabricator layout (design) profitable pipe
and tubing designs saving set up costs (material waste) on any brand of bender.   Above you can click on view a demo of the tube bending software and see in minutes how beneficial this software is for any brand of tube benders.  This layout software can be learned in minute and will save the pipe bender tons of money in material savings.  Our tube bending software helps the fabricator layout profitable pipe and tubing designs, saving set up costs on all brands of tube benders


Features

• Easy Design Input

• Pick Points for Dimensional Placement

• Parametric Style Interface

• CLR or Inside Radius (adjustable for each bend)

• Bend Allowance & K-factor available

• Rotate Sections to Create a True 3D Part

• Material Data Base

• Parts are Placed in a Data Base for Future Retrieval

• Graphical Part Recall

• Help Functions are Fully Video Scripted (Learn BEND-TECH in 30 Minutes)

• 3D Shaded Model can be Rotated Dynamically

• Create prints of the Dimensional Model, Shaded Model, Flat Layout & Title Block

• Flat Development for Cut Length & Bending Locations

• Dimension; Start of Bend, End of Bend & Center of Bend, from either Direction.

• Dimension with Decimals or Fractions

• Flat Includes Bending Data, such as, Bend Angles, CLR or Inside Radius, Rotation Angle, & Bend Order

• Preferences; Colors, Text Sizes & Arrow Sizes are Saved in User Definable Databases

• Our tube bending software (program) helps the fabricator layout (design) profitable pipe and tubing designs saving set up costs (material waste) on any brand of pipe bender
