Laguna Dust Collection

Models
c flux cyclone
p flux cyclone
x flux cyclone
chip separator

Models
MDCCF15110	C\|FLUX: 1
MDCCF22201	C\|FLUX: 2.
MDCCF32201	C\|FLUX: 3.
MDCPF15110	P\|FLUX: 1.
MDCPF22201	P\|FLUX: 2
MDCPF32201	P\|FLUX: 3
MDCXF52201	X\|FLUX: 5
Accessories
PDCCF-FB22	C\|FLUX and P\|FLUX FILTER BAGS, 5 PACK

DUST-101

Click here to download manual

C Flux 1

In 2022, Laguna has updated its line-up of CFlux and PFlux cyclones, and launched the all-new XFlux 5 dust collector!

For the popular C|Flux cyclone dust collectors, weâve kept the user-friendly aspects of the previous generation while adding smart new features to improve the user experience. Among the upgrades is a dual-paddle filter cleaning design, and a max level indicator to increase filter longevity. The iconic octagonal drum grows to an impressive 46-gallon capacity on the C|Flux 2 and 3 models, and the newly redesigned 3-piece drum construction requires far fewer joints and fasteners cutting assembly time, while the locking casters provide additional stability.

Features:

1.5 HP Motor
900CFM Of Air Flow
25 Gallon Octagon Drum

C Flux 1 Specifications
Motor Specs:	1.5HP
Electrical Specs:	110V/220V / 60Hz / 1PH / 3450 RPM
Running AMP:	with 6 inch inlet) 18.8A at 110V; 9.4A at 220V
Air Volume:	900CFM (Cubic Feet Per Minute)
Max Static Pressure:	10.1 inch
Fan Size:	13.5 inch
Inlet:	One 6 inch or Two 4 inch Ports
Remote Control:	High Frequency
Collection Capacity:	25 Gallon Octagon Drum
Decibel Reading:	82 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	42 x 25 x 68 inch
Packing Size (L x W x H):	45 x 28.3 x 47 inch (114.5 x 72 x 119.5 cm)
Machine Weight:	232 lbs. (105 kg)
Shipping Weight:	287 lbs. (130 kg)
Filtering Area:	48.4 sq/ft (4.5 sq/m)
Cartridge Filter:	1 Micron, 15.74 x 19.68 inch (40 x 50 cm) x 1pc

Click here to download manual

C Flux 2

In 2022, Laguna has updated its line-up of CFlux and PFlux cyclones, and launched the all-new XFlux 5 dust collector!

Features:

2 HP Motor
1166CFM Of Air Flow
46 Gallon Octagon Drum

C Flux 2 Specifications
Motor Specs:	2HP
Electrical Specs:	220V/ 60Hz / 1PH / 3450 RPM
Running AMP:	(6 inch inlet) 14A at 220V
Air Volume:	1166CFM (Cubic Feet Per Minute)
Max Static Pressure:	9.3 inch
Fan Size:	14.5 inch
Inlet:	One 6 inch or Two 4 inch Ports
Remote Control:	High Frequency
Collection Capacity:	46 Gallon Octagon Drum
Decibel Reading:	88 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	48 x 28 x 87 inch
Packing Size (L x W x H):	50 x 31.5 x 50.6 inch (127 x 80 x 128.5 cm)
Machine Weight:	301 lbs. (140 kg)
Shipping Weight:	377 lbs. (171 kg)
Filtering Area:	102 sq/ft (9.5 sq/m)
Cartridge Filter:	1 Micron, 15.74 x 35.43 inch (40 x 90 cm) x 1pc

Click here to download manual

C Flux 3

In 2022, Laguna has updated its line-up of CFlux and PFlux cyclones, and launched the all-new XFlux 5 dust collector!

Features:

3 HP Motor
1624CFM Of Air Flow
46 Gallon Octagon Drum

C Flux 3 Specifications
Motor Specs:	3HP
Electrical Specs:	220V / 60Hz / 1PH / 3450 RPM
Running AMP:	(8 inch Inlet) 22A at 220V
Air Volume:	1624CFM (Cubic Feet Per Minute)
Max Static Pressure:	11.2 inch
Fan Size:	15.5 inch
Inlet:	8 inch (8 x 4 inch X 3 Ports)
Remote Control:	High Frequency
Collection Capacity:	46 Gallon Octagon Drum
Decibel Reading:	88 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	48 x 28 x 88 inch
Packing Size (L x W x H):	50 x 31.5 x 50.6 inch (127 x 80 x 128.5 cm)
Machine Weight:	373 lbs. (169 kg)
Shipping Weight:	441 lbs. (200 kg)
Filtering Area:	102 sq/ft (9.5 sq/m)
Cartridge Filter:	1 Micron, 15.74 x 35.43 inch (40 x 90 cm) x 1pc

Click here to download manual

P Flux 1

The P|Flux series gets a host of exciting new upgrades including an auto-cleaning feature standard on all models in this line. The auto-clean conveniently activates every 10 minutes, or you can simply activate from the sleek redesigned remote. Overfilling the drum is a thing of the past, thanks to the super-sized 46 gallon octagonal drum (P|Flux 2 and 3), and a bright LED light illuminating the drum on all P|Flux models. Plus, LED and audio warning lets you know when the drum is full â features that are now standard in this line.

Features:

1.5 HP Motor
900CFM Of Air Flow
25 Gallon Octagon Drum

P Flux 1 Specifications
Motor Specs:	1.5HP
Electrical Specs:	110V/220V / 60Hz / 1PH / 3450 RPM
Running AMP:	with 6 inch inlet) 18.8A at 110V; 9.4A at 220V
Air Volume:	900CFM (Cubic Feet Per Minute)
Max Static Pressure:	10.1 inch
Fan Size:	13.5 inch
Inlet:	One 6 inch or Two 4 inch Ports
Remote Control:	High Frequency
Collection Capacity:	25 Gallon Octagon Drum
Decibel Reading:	70 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	42 x 25 x 68 inch
Packing Size (L x W x H):	45 x 28.3 x 47 inch (114.5 x 72 x 119.5 cm)
Machine Weight:	232 lbs. (105 kg)
Shipping Weight:	287 lbs. (130 kg)
Filtering Area:	48.4 sq/ft (4.5 sq/m)
Cartridge Filter:	HEPA, 15.74 x 19.68 inch (40 x 50 cm) x 1pc
The non-stick PTFE membrane has some disintegration after 200,000 cycles at the area where the cleaning paddles/arms touch the filter media. This does not largely affect the filtration efficiency. The HEPA filter media used on Laguna Cyclones are independently tested by an accredited 3rd party (TTRI). Designed with wide-spaced pleating to maintain optimum performance throughout filter lifespan.

Click here to download manual

P Flux 2

Features:

2 HP Motor
1166CFM Of Air Flow
46 Gallon Octagon Drum

P Flux 2 Specifications
Motor Specs:	2HP
Electrical Specs:	220V/ 60Hz / 1PH / 3450 RPM
Running AMP:	(6 inch inlet) 14A at 220V
Air Volume:	1166CFM (Cubic Feet Per Minute)
Max Static Pressure:	9.3 inch
Fan Size:	14.5 inch
Inlet:	6 inch (8 x 6 inch Port) or 8 inch (8 x 4 inch x 2 Ports)
Remote Control:	High Frequency
Collection Capacity:	46 Gallon Octagon Drum
Decibel Reading:	76 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	48 x 28 x 87 inch
Packing Size (L x W x H):	50 x 31.5 x 50.6 inch (127 x 80 x 128.5 cm)
Machine Weight:	362 lbs. (140 kg)
Shipping Weight:	430 lbs. (171 kg)
Filtering Area:	102 sq/ft (9.5 sq/m)
Cartridge Filter:	HEPA, 15.74â³ x 35.43â³ (40 x 90 cm) x 1pc
The non-stick PTFE membrane has some disintegration after 200,000 cycles at the area where the cleaning paddles/arms touch the filter media. This does not largely affect the filtration efficiency. The HEPA filter media used on Laguna Cyclones are independently tested by an accredited 3rd party (TTRI). Designed with wide-spaced pleating to maintain optimum performance throughout filter lifespan.

Click here to download manual

P Flux 3

The P|Flux series gets a host of exciting new upgrades including an auto-cleaning feature standard on all models in this line. The auto-clean conveniently activates every 10 minutes, or you can simply activate from the sleek redesigned remote. Overfilling the drum is a thing of the past, thanks to the super-sized 46-gallon octagonal drum (P|Flux 2 and 3), and a bright LED light illuminating the drum on all P|Flux models. Plus, LED and audio warning lets you know when the drum is full â features that are now standard in this line.

Features:

3 HP Motor
1624CFM Of Air Flow
46 Gallon Octagon Drum

C Flux 3 Specifications
Motor Specs:	3HP
Electrical Specs:	220V / 60Hz / 1PH / 3450 RPM
Running AMP:	(8 inch Inlet) 22A at 220V
Air Volume:	1624CFM (Cubic Feet Per Minute)
Max Static Pressure:	11.2 inch
Fan Size:	15.5 inch
Inlet:	8 inch (8 x 4 inch X 3 Ports)
Remote Control:	High Frequency
Collection Capacity:	46 Gallon Octagon Drum
Decibel Reading:	76 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	48 x 28 x 88 inch
Packing Size (L x W x H):	50 x 31.5 x 50.6 inch (127 x 80 x 128.5 cm)
Machine Weight:	372 lbs. (169 kg)
Shipping Weight:	441 lbs. (200 kg)
Filtering Area:	102 sq/ft (9.5 sq/m)
Cartridge Filter:	HEPA, 15.74 x 35.43 inch (40 x 90 cm) x 1pc
The non-stick PTFE membrane has some disintegration after 200,000 cycles at the area where the cleaning paddles/arms touch the filter media. This does not largely affect the filtration efficiency. The HEPA filter media used on Laguna Cyclones are independently tested by an accredited 3rd party (TTRI). Designed with wide-spaced pleating to maintain optimum performance throughout filter lifespan.

Click here to download manual

X Flux 5

The all-new X|Flux 5 boasts a powerful 5hp motor and impressive 1823 CFM. Auto-cleaning of the HEPA filter is accomplished by double-paddles that sweep the filter every 3 minutes of system use in a clockwise and counterclockwise action. Remote and LED drum light are standard. The X|Flux 5 is a full-size stationary, single-stage dust collection unit with convenient 39 gallon drum on locking castors.

Click here to download manual

X Flux 5

Features:

5 HP Motor
1832CFM Of Air Flow
39 Gallon Octagon Drum

X Flux 5 Specifications
Motor Specs:	5HP
Electrical Specs:	220V / 60Hz / 1PH / 3450 RPM
Running AMP:	(8 inch Inlet) 22A at 220V
Air Volume:	1823CFM (Cubic Feet Per Minute)
Max Static Pressure:	12 inch
Fan Size:	14.5 inch
Inlet:	8 inch
Remote Control:	High Frequency
Collection Capacity:	39 Gallon Octagon Drum
Decibel Reading:	69 dB ( at 9.8ft)
Assembled Dimensions (L x W x H):	36 x 38 x 91 inch
Packing Size (L x W x H):	35.4 x 28.3 x 81.5 inch (90 x 72 x 207 cm)
Machine Weight:	456 lbs. (207 kg)
Shipping Weight:	544 lbs. (247 kg)
Filtering Area:	32.3 sq/ft (3 sq/m)
Cartridge Filter:	HEPA 19.7 x 19.7 inch (50 x 50 cm) x 1pc; (0.3 - 0.4 Micron at 99.7 percent Efficiency)
The non-stick PTFE membrane has some disintegration after 200,000 cycles at the area where the cleaning paddles/arms touch the filter media. This does not largely affect the filtration efficiency. The HEPA filter media used on Laguna Cyclones are independently tested by an accredited 3rd party (TTRI). Designed with wide-spaced pleating to maintain optimum performance throughout filter lifespan.


JET Cyclonic Separator	JET Cyclonic Separator with bin

JET Cyclonic Separator

The JET Cyclonic Separator maximizes dust collection efficiency by maintaining the air flow of a dust collection system by deflecting chips and large debris inline freeing up dust collection filters to trap fine particles. The red bullet separator deflects chips down ward in to a bin, reducing damage and obstruction to the dust collection hoses, impellors and filters.The JET Cyclonic Separator can be placed on the lid of almost any size container. Bolt pattern is included. Bring cyclonic power and efficiency inline.

Features:

For best performance, select cutterhead and cutting speed to produce chips 2â or smaller
Clear Polycarbonate material allows for viewing of separation
Extends the life of the filter and impellers by extracting the larger debris before entering the dust collector
Includes: (2) 4 inch Wire Hose Clamps
Maintain the air flow of a dust collection system by deflecting chips and large debris inline freeing up dust collection filters to trap fine particles.
The JET Cyclonic Separator can be placed on the lid of almost any size container. Bolt pattern is included.
The red bullet separator deflects chips to a bin, reducing damage and obstruction to the dust collection hoses, impellors, and filters

Specifications

Footprint (L x W/In.) 15.75 x 8.7
1-Hose Connection Diameter (In.) 4
Overall Dimensions (L x W x H) (In.) 15.75 x 8.7 x 11.1

JET Cyclonic Separator with Bin

The JET Cyclonic Separator maximizes dust collection efficiency by maintaining the air flow of a dust collection system by deflecting chips and large debris inline freeing up dust collection filters to trap fine particles. The red bullet separator deflects chips down ward in to a bin, reducing damage and obstruction to the dust collection hoses, impellors and filters.The JET Cyclonic Separator can be purchased with a 30 gallon steel bin that includes handles and 360* casters. The JET Cyclonic Separator also can be placed on the lid of almost any size container. Bolt pattern is included. Bring cyclonic power and efficiency inline.

Features:

For best performance, select cutterhead and cutting speed to produce chips 2â or smaller
Clamping metal lid with gaskets prevents loss of suction.
Clear Polycarbonate material allows for viewing of separation
Durable metal 30-gallon collection bin with window for viewing the fill capacity.
Extends the life of the filter and impellers by extracting the larger debris before entering the dust collector
Includes: (2) 4 inch Wire Hose Clamps
Maintain the air flow of a dust collection system by deflecting chips and large debris inline freeing up dust collection filters to trap fine particles.
Swivel Casters and handle on bin make it easy to move around the shop
The red bullet separator deflects chips to a bin, reducing damage and obstruction to the dust collection hoses, impellors, and filters

Specifications

Collection Drum Capacity (gal.) 20
Footprint (L x W/In.) 20.9 x 16.6
1-Hose Connection Diameter (In.) 4
Overall Dimensions (L x W x H) (In.) 20.9 x 16.6 x 30.5

Jet Cyclonic Separator Models and Accessories
717600	JET Cyclonic Separator
717650	JET Cyclonic Separator with bin
JW1000	Reducer, 4 in to 2-1/4 in OD/2 in ID for JET dust collectors
JW1022	4 in Hose Clamp Dust Collection Accessory
JW1031	JW1031 VCUUM/Dust Collector Hose
JW1032	Dust Collection Hose for Dust Collectors, 4 in dia x 20 ft L
JW1034	Clear Dust Collection Hose, 4 in x 10 ft
JW1043	4 in Connector Sleeve Dust Collection Accessory
JW1317	4 in Wire Clamp Dust Collection Accessory
